Section 1 Configuration
Rev. 2.00 Sep. 08, 2008 Page 2 of 20
REJ10J1394-0200
CAUTION
Use an NQPACK120SE-ND socket and an HQPACK120SE
cover (manufactured by Tokyo Eletech Corporation) for the
PLQP0120LA-A-packaged IC socket on the user system.
Table 1 HS1651ECN61H Components
No. Component Quantity Remarks
1 Board 1
2 IC socket 1 For the PLQP0120LA-A package
3 Socket cover 1 For installing an PLQP0120LA-A packaged MCU
4 Screw (M2.0 x 10 mm) 4 For fastening cable head
5 Screw (M2.0 x 6 mm) 4 For installing an PLQP0120LA-A packaged MCU
6 Guide pins (
φ1 mm)
3 For determining the IC socket location
7 Spacers (2.6 MP x 25 mm) 2
8 Screwdriver 1 For tightening screws
9 User’s manual 1 User’s manual for HS1651ECN61H (this manual)
