Renesas H8SX/1651 User Manual
Page 28
Section 3 Installing the MCU on the User System
Rev. 2.00 Sep. 08, 2008 Page 14 of 20
REJ10J1394-0200
MCU
Pin 1
IC socket
(NQPACK120SE-ND
manufactured by
Tokyo Eletech Corporation)
User system
Screws (M2.0 x 6 mm)
Socket cover
(HQPACK120SE
manufactured by
Tokyo Eletech Corporation)
Figure 9 Installing the MCU on the User System
