8.1 Technical specification
Nominal supply voltage 12 or 24 V dc
Operating voltage range 10.7 to 32 V dc
Fuse / Breakers In-line fuse (fitted within power cable)
• 7 A. (Standard 20 mm glass fuse)
Current 4 A max operating current
Power consumption 32 W typical power consumption
Environmental Installation environment
• Operating temperature: –10 ºC to
50 º (14 ºF to 122 ºF
• Non-operating temperature:
—20 ºC to 70 ºC (-4 ºF to 158 ºF)
• Relative humidity: max 95%
• Water proof to IPX6
Storage conditions (when packed):
• Temperature: —25 ºC to 55 ºC
(-13 ºF to 158 ºF)
• Relative humidity: max 75%
Weight • C90W: 3.8 kg (8.5 lb)
• C120W: 4.8 kg (10.5 lb)
• C140W: 5.6 kg (12.3 lb)
Display screen TFT LCD display, 24bit color (16.7 M
colors)
• C90W: 9 in display, 800 x 480 pixels
• C120W: 12 in display, 1280 x 800
pixels
• C140W: 14 in display, 1280 x 800
pixels
Data connections. 3 x NMEA 0183 ports:
• NMEA port 1: I/O 4800/9600 baud.
• NMEA port 2: I/O 4800/9600/38400
baud.
• NMEA port 3: Input only, 4800
baud.
1 x SeaTalk port.
2 x SeaTalk
hs RJ45 type connections
• 10/100 Mbits/S
1 x SeaTalk ng connection
74 C-Series Widescreen installation
