31 Regency Bellavista™ B36X Gas Fireplace
VENTING ARRANGEMENT - VERTICAL TERMINATIONS
CO-LINEAR FLEX SYSTEM
INTO MASONRY FIREPLACES
FOR BOTH RESIDENTIAL & MANUFACTURED HOMES
The shaded area in the diagrams show the allowable vertical terminations.
INSTALLATION
30'
Max.
8'
Min.
51-1/4”
30
Horizontal Distance (Feet)
V
ertical
Height
(feet)
8'
Min.
49”
30'
Max.
30
Horizontal Distance (Feet)
V
ertical
Height
(feet)
2’
max.
Combined
min.
of
8
’.
6’
max.
49”
Combined
max.
of
30
'.
30
Horizontal Distance (Feet)
V
ertical
Height
(feet)
2’
max.
Restrictor
1” Open
Restrictor
2” Open
Restrictor
1” Open
Restrictor
2” Open
Restrictor
1” Open
Restrictor
2” Open
Use Reducer
# 946-606 &
#770-994 Rigid
Pipe Adaptor Use Reducer
# 946-606 &
#770-994 Rigid
Pipe Adaptor Use Reducer
# 946-606 &
#770-994 Rigid
Pipe Adaptor
