2. Installation
Runco CL-510/ CL-510LT User’s Manual
14
Throw Distance Chart For CL-510LT (With 2.30 - 3.00 Lens)
CL-510LT @ 1280 x 720
Screen Height Screen Width
Min Throw
Distance
Max Throw
Distance
Vertical Offset
Position
40.5 72 165.60 216.00 7.20
43 77 177.10 231.00 7.70
45 80 184.00 240.00 8.00
47 84 192.24 250.98 8.37
49 87 200.10 261.00 8.70
50 89 204.70 267.00 8.90
51.5 92 211.60 276.00 9.20
52 93 213.90 279.00 9.30
54 96 220.80 288.00 9.60
56 100 230.00 300.00 10.00
58 103 236.90 309.00 10.30
58.5 104 239.20 312.00 10.40
60 107 246.10 321.00 10.70
61 109 250.70 327.00 10.90
63 112 257.60 336.00 11.20
65 116 266.80 348.00 11.60
67.5 120 276.00 360.00 12.00
72 128 294.40 384.00 12.80
80 142 326.60 426.00 14.20
82 146 335.80 438.00 14.60
90 160 368.00 480.00 16.00
Screen Hight Screen Width Min TD Max TD Vertical Offset
(SWx2.30) (SWx3.00) SWx0.10
