2. Installation
Runco CL-510/ CL-510LT User’s Manual
10
❚ Adjust the Lens Zoom/Focus ring
❚ Adjust the height
Adjust the projected image size you need with the
zoom ring on the lens. To focus the image, rotate the
focus ring on the lens.
There are 4 screw adjusters on the bottom of this
unit. You can adjust the height or projection angle of
this unit by using these adjusters.
Focus
Zoom out Zoom in
