2. Installation
Runco CL-510/ CL-510LT User’s Manual
11
Installation For CL-510 (With 1.75 - 2.00 Lens)
Screen __________ (H) x __________ (W)
C) VERTICAL OFFSET:
Screen width x 0.12 = _________ inches from the center of the lens.
B) THROW DISTANCE:
CL-510 16 x 9 Screens:
Minimum: (screen width x 1.75) = __________ inches
Maximum: (screen width x 2.00) = __________ inches
Ceiling
Floor
