2. Installation
Runco CL-510/ CL-510LT User’s Manual
13
Installation For CL-510LT (With 2.30 - 3.00 Lens)
Screen __________ (H) x __________ (W)
C) VERTICAL OFFSET:
Screen width x 0.10 = _________ inches from the center of the lens.
B) THROW DISTANCE:
CL-510LT 16 x 9 Screens:
Minimum: (screen width x 2.30) = __________ inches
Maximum: (screen width x 3.00) = __________ inches
Ceiling
Floor
