Regency ® F39 Room Sealed Freestanding Gas Stove 23
NORMAL
OPERATING
SOUNDS OF GAS
APPLIANCES
It is possible that you will hear some
sounds from your gas appliance. This
is perfectly normal due to the fact that
there are various gauges and types
of steel used within your appliance.
Listed below are some examples. All
are normal operating sounds and
should not be considered as defects in
your appliance.
Blower:
Regency
® gas appliances use high tech
blowers to push heated air farther into
the room. It is not unusual for the fan
to make a "whirring" sound when ON.
This sound will increase or decrease in
volume depending on the speed setting
of your fan speed control.
Burner Tray:
The burner tray is positioned directly
under the burner tube(s) and logs and
is made of a different gauge material
from the rest of the fi rebox and body.
Therefore, the varying thicknesses of
steel will expand and contract at slightly
different rates which can cause "ticking"
and "cracking" sounds. You should also
be aware that as there are temperature
changes within the unit these sounds will
likely re-occur. Again, this is normal for
steel fi reboxes.
Blower Thermodisc:
When this thermally activated switch
turns ON it will create a small "clicking"
sound. This is the switch contacts closing
and is normal.
Pilot Flame:
While the pilot fl ame is on it can make a
very slight "whisper" sound.
Gas Control Valve:
As the gas control valve turns ON and
OFF, a dull clicking sound may be au-
dible, this is normal operation of a gas
regulator or valve.
Unit Body/Firebox:
Different types and thicknesses of steel
will expand and contract at different
rates resulting in some "cracking" and
"ticking" sounds will be heard throughout
the cycling process.
COPY OF THE LIGHTING PLATE INSTRUCTIONS
OPERATING INSTRUCTIONS
1) Push in the gas control knob slightly and turn
clockwise to “OFF”. Do not force.
FOR YOUR SAFETY READ BEFORE LIGHTING
A) This appliance has a pilot which must be lighted
by hand, following the instructions below
exactly.
B) BEFORE LIGHTING smell all around the appliance
area for gas. Be sure to smell next to the floor
because some gas is heavier than air and will
settle on the floor.
WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance
- Do not touch any electric switch, do not use any
phone in your building
- Immediately call your gas supplier from a
neighbors phone. Follow the gas supplier’s in-
structions.
- If you cannot reach your gas supplier, call the
fire department.
C) Use only your hand to push in or turn the gas
control knob. Never use tools. If the knob will not
push in or turn by hand, don’t try to repair it, call
STOP! Read the safety information above on this
label.
1) Push in gas control knob slightly and turn
clockwise to “OFF”. Knob cannot be turned
from “PILOT” to “OFF” unless knob is pushed in
slightly. Do not force.
2) Wait five (5) minutes to clear out any gas. If you
then smell gas STOP! follow “B” in the safety
information above on this label. If you don’t smell
gas, go to the next step.
3) Turn knob on gas control counterclockwise
to “PILOT”.
4) Push in control knob all the way and hold in.
Immediately push black button on spark igniter
until pilot lights. Continue to hold the control
knob in for about 1/2 minute after the pilot is lit.
Release knob and it will pop back up. Pilot should
remain lit. If it goes out, repeat steps 3) and 4).
If knob does not pop up when released, stop and
immediately call your service technician or gas
supplier.
If the pilot will not stay lit after several tries, turn the
gas control knob to “OFF” and call your service
technician or gas supplier.
5) Turn gas control knob counterclockwise to “ON”.
6) Use rocker switch to operate main burner.
908-649c
Gas Inlet
OFF
WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing
property damage, personal injury or loss of life. Improper installation, adjustment, alteration, service
or maintenance can cause injury or property damage. Refer to the owner’s information manual
provided with this appliance. For assistance or additional information consult a qualified installer,
service agency or gas supplier.
a qualified service technician. Force or attempted
repair may result in a fire or explosion.
D) Do not use this appliance if any part has been under
water. Immediately call a qualified service techni-
cian to inspect the appliance and to replace any part
of the control system and any gas control which has
been under water.
This appliance needs fresh air for safe operation and
must be installed so there are provisions for adequate
combustion and ventilation air.
LIGHTING INSTRUCTIONS
TO TURN OFF GAS APPLIANCE
THERMOPILE
ELEMENT
THERMO-
ELECTRIQUE
PILOT BURNER
VEILLEUSE
This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI
Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. (Australia: AS5601-2004, New Zealand: NZS 5261)
DO NOT REMOVE THIS INSTRUCTION PLATE
CAUTION: Hot while in operation. Do not touch.
Severe Burns may result. Due to high surface
temperatures keep children, clothing and
furniture, gasoline and other liquids having
fammable vapors away. Keep burner and control
compartment clean. See installation and
operating instructions accompanying appliance.
2) Turn off all electric power to the appliance if
service is to be performed.
You may shut off the pilot during prolonged non use periods to conserve fuel.
