Page 26
Chapter 3
Installation
RuggedBackbone™ RX5000
Installation Guide
20
AC Power Supply Wiring
Section 3.2.2
AC Power Supply Wiring
Figure 22: AC Power Schematic – Integrated Earth Connection
NOTE
Figure 20, “RX5000 Power Connector”
is not connected to safety earth,
a connection must be provided from the chassis ground terminal, as shown in
Schematic – Separate Earth Connection”
.
