RuggedBackbone™ RX5000
Installation Guide
Chapter 3
Installation
Rack Rear Mounting
15
Section 3.1.1.3
Rack Rear Mounting
Assemble the rack mount brackets to the main chassis using six (6) #10-32 × 3/8" flat head steel screws
(supplied) on each side. Screws are to be torqued to 18±1 in-lb. The brackets can be mounted either as shown
above, or extended by 1".
