Raypak RayTemp Hot Water Energy Management Control - Manual (Page 14)

14
Section 4. PROGRAMMING
QUICK REFERENCE
This section describes all the programmable features of the control. You make program changes
from the front panel or by using a laptop. For information on connection with a LapTop using PTT
software, refer to the previous section. The following keys provide access to all RayTemp display
and programming features. These keys apply to the front panel or LapTop display as shown
below. A screen saver clears the display after five minutes on the LapTop. Press F1, then F6 to
restore the screen.
Front Panel
Key
Laptop
or PC Key
Screen Selected
WINDOW
UP & DOWN
F1
Returns to first screen, then press two
keys for direct access to any screen as
listed on the next screen
WINDOW DOWN F2 Select next screen
WINDOW UP F3 Select previous screen
VALUE+ F4 Increase program value
VALUE- F5 Decrease program value
FIELD RIGHT SPACE Select next field in a screen
FIELD LEFT BACKSPACE Select previous field in a screen
F6
Activate full-screen viewing (PC with
PTT only)
SHIFT F6
