REMINGTON® ELECTRIC TRIMMER/EDGER | 3
118035
2 product identification
A. Motor Housing
B. Spool Housing
C. Cutting Guard
D. Edging Wheel
E. Adjustable Front Handle
F. Rear Handle
G. Inlet Plug or Power Cord
H. Extension Cord Retainer
I. Trigger Switch
J. Trigger Switch Safety Button
K. Shaft Rotation Button
L. Telescoping Shaft
M. Telescope Release Button
Specifications
ST3812B ST4514B
Input
No Load Speed
Cutting Width
Net Weight
Line Diameter 120V, 3.8A
1000 spm
12 inches (45.7cm)
6.35 lbs. (2.88 Kg)
0.065 inch 120V, 4.5A
1000 spm
14 inches (55.9cm)
6.35 lbs. (2.88 Kg)
0.065 inch
Figure 2-1: Remington® electric trimmer/edger (model ST3812B shown)
A
B
L
M
K
J
I
H
G
F
E
D
C
