Chapter 4: Trimmer/Edger Operation
Converting to Edger
This tool easily converts to an trimmer/
edger. Follow the steps below.
1. Slide telescope release button upward
toward handle (see Figure 4-27).
2. Adjust shaft to desired length and
release button (see Figure 4-28).
Note: Make sure inner shaft locks
into one of the preset notches before
operating.
3. Press the shaft rotation button lo-
cated on the rear handle (see Figure
4-29).
4. Holding the rear handle in place,
grasp the front handle and rotate
the shaft and power head 180° to the
edging position (see Figure 4-30).
5. Release the shaft rotation button.
6. Loosen knob on front handle. Rotate
handle 180° and tighten knob.
Figure 4-29: Pressing shaft rotation release button
Figure 4-30: Rotating shaft and power head
Using Edger
1. Make sure trimmer/edger line is
advanced to full cutting length.
2. Roll the trimmer/edger using the
edging wheel attached to the cutting
guard (see Figure 4-31).
3. Start the trimmer/edger and trim
along edging lines. Be sure to keep
the cutting lines vertical.
Figure 4-31: Edging
Figure 4-27: Sliding telescoping release button upward
Figure 4-28: Adjusting shaft length
