MIDI Implementation
❍ Vibrato Rate (Controller number 76)
Status 2nd byte 3rd byte
BnH 4CH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Rate value (relative change) : 00H - 40H - 7FH (-64 - 0 - +63)
* The Vibrato Rate parameter (Perform Tone Edit) will change.
❍ Vibrato Depth (Controller number 77)
Status 2nd byte 3rd byte
BnH 4DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Depth Value (relative change) : 00H - 40H - 7FH (-64 - 0 - +63)
* The Vibrato Depth parameter (Perform Tone Edit) will change.
❍ Vibrato Delay (Controller number 78)
Status 2nd byte 3rd byte
BnH 4EH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Delay value (relative change) : 00H - 40H - 7FH (-64 - 0 - +63)
* The Vibrato Delay parameter (Perform Tone Edit) will change.
❍ General Purpose Controller 5 (Controller number 80)
Status 2nd byte 3rd byte
BnH 50H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 6 (Controller number 81)
Status 2nd byte 3rd byte
BnH 51H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 7 (Controller number 82)
Status 2nd byte 3rd byte
BnH 52H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ General Purpose Controller 8 (Controller number 83)
Status 2nd byte 3rd byte
BnH 53H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
❍ Portamento control (Controller number 84)
Status 2nd byte 3rd byte
BnH 54H kkH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = source note number: 00H - 7FH (0 - 127)
* A Note-on received immediately after a Portamento Control message will change
continuously in pitch, starting from the pitch of the Source Note Number.
* If a voice is already sounding for a note number identical to the Source Note Number,
this voice will continue sounding (i.e., legato) and will, when the next Note-on is
received, smoothly change to the pitch of that Note-on.
* The rate of the pitch change caused by Portamento Control is determined by the
Portamento Time value.
❍ Effect 1 (Reverb Send Level) (Controller number 91)
Status 2nd byte 3rd byte
BnH 5BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Reverb Send Level: 00H - 7FH (0 - 127)
* The Reverb Send Level parameter (Perform Tone Edit) will change.
❍ Effect 3 (Chorus Send Level) (Controller number 93)
Status 2nd byte 3rd byte
BnH 5DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Chorus Send Level: 00H - 7FH (0 - 127)
* The Chorus Send Level parameter (Perform Tone Edit) will change.
❍ RPN MSB/LSB (Controller number 100, 101)
Status 2nd byte 3rd byte
BnH 65H mmH
BnH 64H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm = upper byte (MSB) of parameter number specified by RPN
ll = lower byte (LSB) of parameter number specified by RPN
<<< RPN >>>
Control Changes include RPN (Registered Parameter Numbers), which are extended.
When using RPNs, first RPN (Controller numbers 100 and 101; they can be sent in any
order) should be sent in order to select the parameter, then Data Entry (Controller numbers
6 and 38) should be sent to set the value. Once RPN messages are received, Data Entry
messages that is received at the same MIDI channel after that are recognized as changing
toward the value of the RPN messages. In order not to make any mistakes, transmitting
RPN Null is recommended after setting parameters you need.
This device receives the following RPNs.
RPN Data entry
MSB, LSB MSB, LSB Notes
00H, 00H mmH, llH Pitch Bend Sensitivity
mm: 00H - 18H (0 - 24 semitones)
ll: ignored (processed as 00H)
Up to 2 octave can be specified in semitone steps.
* The Pitch Bend Range parameter (Perform Tone Edit) will change.
00H, 01H mmH, llH Channel Fine Tuning
mm, ll: 20 00H - 40 00H - 60 00H
(-4096 x 100 / 8192 - 0 - +4096 x 100 / 8192 cent)
00H, 02H mmH, llH Channel Coarse Tuning
mm: 10H - 40H - 70H (-48 - 0 - +48 semitones)
ll: ignored (processed as 00H)
00H, 05H mmH, llH Modulation Depth Range
mm: 00 00H - 06 00H
(0 - 16384 x 600 / 16384 cent)
7FH, 7FH ---, --- RPN null
RPN and NRPN will be set as “unspecified.”
Once this setting has been made, subsequent
Parameter values that were previously set will
not change.
mm, ll: ignored
● Program Change
Status 2nd byte
CnH ppH
n = MIDI channel number: 0H - FH (ch.1 - 16)
pp = Program number: 00H - 7FH (prog.1 - prog.128)
* Not received when the Rx Program Change parameter (SYSTEM MIDI) is OFF.
● Channel Pressure
Status 2nd byte
DnH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Channel Pressure: 00H - 7FH (0 - 127)
● Pitch Bend Change
Status 2nd byte 3rd byte
EnH llH mmH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Pitch Bend value: 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)
* Not received when the Rx Pitch Bend parameter (SYSTEM MIDI) is OFF.
