12
MOUNTING THE STEREO
Once you verify that the stereo is con-
nected properly, follow these steps to
mount the stereo.
1. Disconnect the cable from the vehi-
cle’s negative (–) battery terminal.
2. Disconnect the wiring harness and
the antenna.
3. Press REL on the right side of the
control panel to remove it (see
“Removing the Control Panel” on
Page 15).
4. With the supplied keys’ tabs facing
inward, insert both of the keys into
the slots between the mounting
sleeve and the stereo and press the
keys toward the back of the stereo.
The sleeve begins to slide off.
Vehicle’s
Antenna
Wiring
Harness
Sleeve
5. Remove the keys from the slots and
slide the sleeve all the way off.
6. Put the sleeve into the opening in
the dash, then secure it by bending
out all the tabs with a screwdriver.
7. Pull the wiring harness and the
antenna cable through the sleeve
and dash, then reconnect the wiring
harness and the antenna to the ste-
reo.
