RCA RCR412S - Manual (Page 6)

11 10
Code Retrieval (continued)
2. While holding the component key down,
press and hold the INFO key. The
illuminated ON·OFF key turns off.
3. After holding down both keys for three
seconds, the illuminated ON·OFF key
turns back on.
4. Release both keys. The illuminated
ON·OFF key remains on.
5. Starting with the number 1 key, press
and release each number key on the
keypad in the following order (1-9,
then 0). The number that causes the
illuminated ON·OFF key to blink is the
first number of the code. As you find
each number of the code, write them
down for future reference.
ON·OFF
(ON)
ON·OFF
(OFF)
INFO
ON·OFF
(BLINK)
Note: All TV codes begin with the number 1;
all VCR codes begin with the number 2;
all DVDs, the number 3; and all satellite
receivers and cable boxes, the number 5.
6. Repeat step 5 until you have retrieved
all four numbers in the code.
7. After the fourth number is retrieved, the
illuminated ON·OFF key blinks briefly,
then turns off.
ON·OFF
(OFF)
! TIP: To exit the Code Retrieval Mode, press
and release the GO BACK key at any time.
GO BACK
Note: If you press an invalid key during the Code Retrieval process,
the remote will not respond. If you do not press a valid Code
Retrieval key (TV, DVD, VCR·AUX, SAT·CBL, INFO, GO BACK),
Code Retrieval times out after 15 seconds. The illuminated ON·OFF
key blinks four times, and then turns off.
TV CODE
1
VCR·AUX CODE
DVD CODE
3
SAT·CBL CODE
5
VCR DVD TV SAT·CBL SAT CBL
Because this remote controls more than one component, you must first
“tell” the remote which component you wish to operate. That means, if
you wish to operate your TV, you must first press the TV key to put the
remote in the TV Mode.
The remote stays in the chosen component mode (such as TV Mode)
until you change it. If your remote is in TV Mode, you must change
the mode in order to operate your DVD or VCR, auxiliary component,
satellite receiver or cable box. For example, if you are in VCR Mode,
and you wish to turn off your TV, you must press the TV key first
before pressing the ON·OFF key.
Using the Remote to Control
Your Components
Accessing and Selecting Menu Items
Today’s advanced components use on-screen menus to help you
navigate through all their features and functions. While this remote
cannot access every menu system of every component model, it does
offer some menu functionality.
On-screen Menus
SAT·CBL DVD
VCR·AUX
TV To use a component’s on-screen menu
system, you first have to put the remote
in Menu Mode.
1. Make sure your components are turned
on and your TV is set to the component’s
input mode (Use the INPUT key to toggle
through inputs when in TV Mode.)
2. Press the component key whose menu
you want to access.
3. Press the MENU key. The illuminated
ON·OFF key blinks, indicating you are
in the Menu Mode.
4. Use the VOL+/- and/or CH+/- keys
to navigate through the on-screen
menu system.
5. To make a selection from the on-screen
menu, press the MENU or OK key to
select the highlighted item.
ON·OFF
(BLINK)
VOL & CH
MENU OK
! TIP: If the remote doesn’t respond, check to see that the
illuminated ON·OFF key is still blinking. Remember: it times out after
20 seconds. If this happens, just press the MENU key again, and then
retry your selection.
Exiting a Menu Mode
The remote automatically times out of Menu Mode after 20 seconds of
inactivity (no keys being pressed). At that time, the remote clears the
displayed menu from the TV.
If you want to exit the Menu Mode yourself, press the corresponding
component key on the remote (TV, DVD, VCR·AUX, SAT·CBL). The
illuminated ON·OFF key turns off.
MENU
TV 1. Press and release the TV key.
2. Press and hold the SLEEP key for three
seconds. The illuminated ON·OFF key
turns on.
3. Release the SLEEP key.
4. Using the number keys, enter the desired
time in minutes (from 01-99 minutes). To
set the timer to a number under 10
minutes, first press 0 and then the
desired number (e.g., 05 for five
minutes). The illuminated ON·OFF key
blinks with each keypress.
5. Once the second number is entered, the
illuminated ON·OFF key turns off.
Sleep Timer (Select Models Only)
This feature automatically turns off your TV at a duration you choose
from 1 to 99 minutes. The Sleep Timer only works if you have found a
code that controls your TV. The timing mechanism for the Sleep Timer
is built into your universal remote control. To program the Sleep Timer,
follow these steps.
Programming the Sleep Timer
SLEEP
ON·OFF
(ON)
ON·OFF
(BLINK)
ON·OFF
(OFF)
