Battery Saver

Your universal remote control saves battery power by

automatically turning off if any key is pressed for more than

60 seconds. This saves your battery life should your remote

get stuck in a place where the keys remain depressed, such as

between sofa cushions.

RCR4283N /
RCR4383N

Universal Remote Control
Owner’s Manual

Manual del Propietario (parte posterior)

SAVE THIS MANUAL AND THE CODE LISTS!
Remote controls can sometimes lose their programming

when you change the batteries. Make sure you keep the

manual and code lists in a safe place so that you can

reprogram the remote if you need to.

Tip: This remote is already programmed to operate

most RCA-branded TVs, VCRs, DVD players and satellite

receivers. Just press the corresponding key—DVD•VCR

for a DVD player, TV for a television, SAT•CBL•DTC for a

satellite receiver, DVR•AUX for a DVR.

Your universal remote requires two AAA alkaline batteries (not

included).

To install the batteries:

1.

Press and push the battery

compartment cover to remove it.

2.

Insert the batteries, matching

the batteries to the (+) and

(–) marks inside the battery

compartment.

3.

Push the battery cover back into

place.

Battery Precautions:

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc) or

rechargeable (nickel-cadmium) batteries.

• Always remove old, weak or worn-out batteries promptly

and recycle or dispose of them in accordance with Local

and National Regulations.

To use this universal remote with your home entertainment

system, first you need to program it to control your devices.

There are four ways you can program the universal remote to

operate your devices:

The Auto Code Search goes automatically through all the

codes for the device you’re trying to control. It’s the easiest

method, but it can sometimes take longer than some of the

other programming methods.

• The Brand Code Search searches through the codes for

select brands of devices. It’s not as easy as the auto code

search, but it can be faster.

• The Direct Code Entry lets you enter a code from the

accompanying code list for your brand of device. It’s not as

easy as the other methods, but it’s potentially the fastest

method.

• The Manual Code Search lets you manually go through

all the codes for the device you’re trying to control.

Testing the Code for Maximum Functionality
1.
Try a variety of the device’s functions with the remote. If

some device features don’t work, go to the next step to try

a different code.

2. Repeat the Auto Code Search Method from the beginning.

When your device turns off, do not stop searching.

Instead, with the unit now off, continue to press the PLAY

key every 5 seconds until the unit turns back on.

3. Once the unit turns back on, press the REVERSE key on the

remote every 2 seconds until your device turns off again.

When your device turns off again, press the STOP key.

4. Test the key’s functionality again by attempting to control

a variety of the device’s functions. If the code that has

been stored controls the majority of the device’s functions,

programming is complete. If the code stored does not give

maximum functionality, try another code.

Auto Code Search

The Auto Code Search goes automatically through all the

codes for the device you’re trying to control. When you find

the one that operates your device, you can stop the search and

store that code.

TIPS: Each device key is associated with a type of

device—the TV is preset to search for TVs, SAT•CBL•DTC

for satellite receivers, cable boxes or digital TV converters,

DVD•VCR for DVD players, and DVR•AUX for DVRs. To

program a device key for a different type of device, see the

Changing a Key’s Device Type section.

To exit without saving a new code at any point in the Auto

Code Search, press the CLEAR key.

1.

Manually turn on the device you

want to control.

2.

Press and hold the device key you want to program. While

you’re holding down the device key, use your other hand

to press and hold the remote’s POWER key at the same

time.

3.

Wait until the remote’s indicator

indicator light comes on and

stays on. Then release both keys.

4.

Point the remote directly at the

front panel of the device you

want to control. Press PLAY on

the remote and wait 5 seconds.

The remote is testing a batch of

10 codes on your device.

Did your device turn off?

YES: Go to step 5.

NO: Press PLAY again. The remote tests the next batch of

10 codes.

Keep pressing PLAY every 5 seconds until your device turns

off.

5.

When your device turns off, press

the REVERSE key on the remote

and wait at least 2 seconds.

The remote tries the last of the

previous ten codes.

Did your device turn on?

YES: Press the STOP key. You’re

done! You’ve programmed this

device key.

NO: Press REVERSE again. The remote tests the next

code in the batch.

Keep pressing REVERSE every 2 seconds until your device

turns back on. When it does, press STOP.

Note: If you accidentally press the REVERSE key after your

device turns on, press the FORWARD key. Then, wait two

seconds to see if your device turns off again.

NOTES

Throughout the programming of each key, be sure to keep

the remote pointed at the IR sensor of the device you are

currently programming the remote to control.

Test the remote with the device to make sure the

device key is programmed with the correct code for

maximum functionality. If some features don’t work, try

a different code. See the “Testing the Code for Maximum

Functionality” section below for more information.

During the Auto Code Search, the remote ignores

keypresses that aren’t part of the search.

The search times out after two minutes (the indicator light

blinks four times and turns off, and the last programmed

code under that device key is retained).

The indicator light blinks four times and turns off when the

remote has gone through all the codes. The remote exits

the Auto Code Search. If your device hasn’t turned off yet,

try a different search method.

Testing the Code for Maximum Functionality
1.
Try a variety of the device’s functions with the remote. If

some device features don’t work, go to the next step to try

a different code.

2. Repeat the Brand Code Search from the beginning. When

the device turns off for the first time, don’t press the STOP

key, which would store the same code. Instead, with the

unit now off, continue to press the POWER key repeatedly

until the unit turns back on.

3. Once the unit turns back on, you have found another code

that operates the device. Press the STOP key.

4. Test the key’s functionality again by attempting to control

a variety of the device’s functions. If the code that has

been stored controls the majority of the device’s functions,

programming is complete. If the code stored does not give

maximum functionality, try another code.

Brand Code Search

The Brand Code Search goes through only the codes for one of

the select brands listed in the accompanying code list. If your

brand of device is listed, this search can be very quick and easy.

TIPS: Each device key is associated with a type of device—

the TV is preset to search for TVs, SAT•CBL•DTC for satellite

receivers, cable boxes or digital TV converters, DVD•VCR

for DVD players, and DVR•AUX for DVRs. To program a

device key for a different type of device, see the Changing a

Key’s Device Type section.

To exit without saving a new code at any point in the Brand

Code Search, press the CLEAR key.

1.

Manually turn on the device you

want to control.

3.

Press and hold the device key you want to program. While

you’re holding down the device key, use your other hand

to press and hold the remote’s POWER key at the same

time.

4.

Wait until the remote’s indicator

comes on and stays on. Then release

both keys.

6.

Point the remote directly at the

front panel of the device you want

to control. Press POWER on the

remote and wait 2 seconds. The

remote is testing a single code for

your device’s brand.

Did your device turn off?

YES: Press the STOP key to store the code. You’re done!

You’ve programmed this device key.

NO: Press POWER again. The remote tests the next code

for your brand.

Keep pressing POWER every 2 seconds until your device

turns back on. When it does, press STOP.

2.

Find your device’s brand in the

Brand Code list section of the

accompanying code list. Circle

the number for your brand and

keep the list handy.

Cod

e Li

ts

List

a de

Cód

igos

0

1

2

3

4

5

6

7

8

9

V

VCR

0

1

2

3

4

5

6

7

8

9

DVD

SA

/CAB

LE

0

1

2

3

4

5

6

7

8

9

0

1

2

3

4

5

6

7

8

9

5.

Look at the number you circled for

your device’s brand code number.

Press that number on the remote

keypad.

NOTES

Throughout the programming of each key, be sure to keep

the remote pointed at the IR sensor of the device you are

currently programming the remote to control.
Test the remote with the device to make sure the device

key is programmed with the correct code for maximum

functionality. If some features don’t work, try a different

code. See the “Testing the Code for Maximum Functionality”

section below for more information.

During the Brand Code Search, the remote ignores

keypresses that aren’t part of the search.
The search times out after two minutes (the indicator light

blinks four times and turns off, and the last programmed

code under that device key is retained).
The indicator light blinks four times and turns off when the

remote has gone through all the codes. The remote exits the

Brand Code Search. If your device hasn’t turned off yet, try a

different search method.

Direct Code Entry

Direct Code Entry lets you enter a code from the accompanying

code list for your brand of device. It’s not as easy as the other

methods, but it’s potentially the fastest method.

TIP: Each device key is associated with a type of device—

the TV is preset to search for TVs, SAT•CBL•DTC for satellite

receivers, cable boxes or digital TV converters, DVD•VCR

for DVD players, and DVR•AUX for DVRs. To program a

device key for a different type of device, see the Changing a

Key’s Device Type section.

1.

Manually turn on the device you

want to control.

3.

Press and hold the device key you want to program (the

indicator light comes on).

While you’re holding down the device key, use your other

hand enter the first five-digit code for your brand in the

code list (the indicator light goes off after the first digit).

2.

Find the Code List that came with

the remote. Locate the section for

the type of device you’re trying to

program, and find your brand in

that section. Circle the codes for

your brand and keep them handy.

Cod

e Li

sts

List

a de

Cód

igos

0

1

2

3

4

5

6

7

8

9

TV

VCR

0

1

2

3

4

5

6

7

8

9

DVD

SA

CAB

LE

0

1

2

3

4

5

6

7

8

9

0

1

2

3

4

5

6

7

8

9

NOTES
Remember to enter the code for future reference in the box

provided in the Code Retrieval section of this manual.
If your brand isn’t listed in the code list, use one of the Code

Search methods to program the remote control. (Refer to the

Auto and Manual Code Search methods.)

If you release the device key any time during the Direct Code

Entry procedure, the indicator light blinks four times, and

the process is exited. The last programmed code under the

device key is retained.

Test the remote with the device to make sure the device

key is programmed with the correct code for maximum

functionality. If some features don’t work, try a different code

in the list.

4.

When you’ve finished entering

the five-digit code, keep holding

down the device key and look at

the indicator light.

Is the indicator light on?

YES: You’re done! You’ve
programmed this device key.

NO, it blinked four times and turned off: You have

either entered a code number that is not in the code lists

or missed a step in the code entry procedure. Try step 3

again.

Indicator light

Manual Code Search

The Manual Code Search lets you go one-by-one through all the

codes for the device you’re trying to control. When you find the

one that operates your device, you can stop the search and store

that code.

TIPS: The Manual Code Search method may take a long time

because the remote searches through all of the codes in

its memory one-by-one. If your brand is listed in the Brand

Codes or the Code Lists, first try the Brand Code Search or

the Direct Code Entry method.

Each device key is associated with a type of device—the TV is

preset to search for TVs, SAT•CBL•DTC for satellite receivers,

cable boxes or digital TV converters, DVD•VCR for DVD

players, and DVR•AUX for DVRs. To program a device key for

a different type of device, see the Changing a Key’s Device

Type section.

To exit without saving a new code at any point in the Manual

Code Search, press the CLEAR key.

Step 1: Install your batteries

Step 2: Program your remote

This manual is related to the following products:
