Rcrn04gr, Universal remote control owner’s manual, Battery saver

background image

In most cases, the keys on

this remote perform the same

functions as the keys on your

original remotes once you’ve

programmed this remote to

operate your components.

Many keys on this remote

have other functions as well.

Illuminated POWER key

serves as an indicator light to

provide feedback.

Device keys (TV,

SAT•CBL•DTC, DVD•VCR,

DVR•AUX) put the remote in

the right mode to control your

device.

GUIDE and MENU put the

remote in menu/guide mode;

they also access the same

features as the keys on your

original remotes.

EXIT exits remote

programming; it also

performs the same functions

as on your original remotes.

Arrow keys act as navigation

keys in device guides and

menu systems.

The INPUT•DIGITAL and

— (dash) key has three

functions: (1) it toggles

through all the video sources

connected to your TV; (2)

when the remote is in VCR

mode, this button toggles

between VCR and the TV

input; (3) when you’re

entering digital channel

numbers directly, this button

lets you separate the main

channel number from the

sub-channel number (such

as 59.1).

Red, green, yellow, and

blue keys access additional

features on your cable box,

satellite receiver, or Blu-ray

disc player (see your device

manual for details).

Backlight key ( ) turns

backlighting on/off.

Battery Saver

Your universal remote control saves battery power by

automatically turning off if any key is pressed for more than

60 seconds. This saves your battery life should your remote

get stuck in a place where the keys remain depressed, such as

between sofa cushions.

RCRN04GR

Universal Remote Control
Owner’s Manual

Manual del Propietario (parte posterior)

Actual model may vary from

illustration

Care and Maintenance

• Keep the remote dry. If it gets wet, wipe it dry immediately.
• Use and store the remote only in normal temperature environments.
• Handle the remote gently and carefully. Don’t drop it.
• Keep the remote away from dust and dirt.
• Wipe the remote with a damp cloth occasionally to keep it looking new.
• Modifying or tampering with the remote’s internal devices can cause

malfunction and invalidate its warranty.

SAVE THIS MANUAL AND THE CODE LISTS!
Remote controls can sometimes lose their programming

when you change the batteries. Make sure you keep the

manual and code lists in a safe place so that you can

reprogram the remote if you need to.

Tip: This remote is already programmed to operate most

RCA-branded TVs, DVD players, and satellite receivers.

Just press the corresponding key—DVD•VCR for a DVD

player, TV for a television, SAT•CBL•DTC for a satellite

receiver.

Your universal remote requires two AAA alkaline batteries (not

included).

To install the batteries:

1.

Remove the battery

compartment cover.

2.

Insert the batteries, matching

the batteries to the (+) and

(–) marks inside the battery

compartment.

3.

Push the battery cover back into

place.

Battery Precautions:

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc) or

rechargeable (nickel-cadmium) batteries.

• Always remove old, weak or worn-out batteries promptly

and recycle or dispose of them in accordance with Local

and National Regulations.

To use this universal remote with your home entertainment

system, first you need to program it to control your devices.

There are four ways you can program the universal remote to

operate your devices:

The Auto Code Search goes automatically through all the

codes for the device you’re trying to control. It’s the easiest

method, but it can sometimes take longer than some of the

other programming methods.

• The Brand Code Search searches through the codes for

select brands of devices. It’s not as easy as the auto code

search, but it can be faster.

• The Direct Code Entry lets you enter a code from the

accompanying code list for your brand of device. It’s not as

easy as the other methods, but it’s potentially the fastest

method.

• The Manual Code Search lets you manually go through

all the codes for the device you’re trying to control.

Testing the Code for Maximum Functionality
1.

Try a variety of the device’s functions with the remote. If

some device features don’t work, go to the next step to try

a different code.

2. Repeat the Auto Code Search Method from the beginning.

When your device turns off, do not stop searching.

Instead, with the unit now off, continue to press the PLAY

key every 5 seconds until the unit turns back on.

3. Once the unit turns back on, press the REVERSE key on the

remote every 2 seconds until your device turns off again.

When your device turns off again, press the STOP key.

4. Test the key’s functionality again by attempting to control

a variety of the device’s functions. If the code that has

been stored controls the majority of the device’s functions,

programming is complete. If the code stored does not give

maximum functionality, try another code.

Auto Code Search

The Auto Code Search goes automatically through all the

codes for the device you’re trying to control. When you find

the one that operates your device, you can stop the search and

store that code.

TIPS: Each device key is associated with a type of

device—the TV is preset to search for TVs, SAT•CBL•DTC

for satellite receivers, cable boxes or digital TV converters,

DVD•VCR for DVD players, and DVR•AUX for DVRs. To

program a device key for a different type of device, see the

Changing a Key’s Device Type section.

To exit without saving a new code at any point in the Auto

Code Search, press the EXIT key.

1.

Manually turn on the device you

want to control.

2.

Press and hold the device key you want to program. The

POWER key illuminates.

While you’re holding down the device key, use your other

hand to press and hold the remote’s POWER key at the

same time. The POWER key turns off.

3.

Wait until the POWER key comes

on and stays on. Then release

both keys.

4.

Point the remote directly at the

front panel of the device you

want to control. Press PLAY on

the remote and wait 5 seconds.

The remote is testing a batch of

10 codes on your device.

Did your device turn off?

YES: Go to step 5.

NO: Press PLAY again. The remote tests the next batch of

10 codes.

Keep pressing PLAY every 5 seconds until your device turns

off.

5.

When your device turns off, press

the REVERSE key on the remote

and wait at least 2 seconds.

The remote tries the last of the

previous ten codes.

Did your device turn on?

YES: Press the STOP key. You’re

done! You’ve programmed this

device key.

NO: Press REVERSE again. The remote tests the next

code in the batch.

Keep pressing REVERSE every 2 seconds until your device

turns back on. When it does, press STOP.

Note: If you accidentally press the REVERSE key after your

device turns on, press the FORWARD key. Then, wait two

seconds to see if your device turns off again.

NOTES

Throughout the programming of each key, be sure to keep

the remote pointed at the IR sensor of the device you are

currently programming the remote to control.

Test the remote with the device to make sure the

device key is programmed with the correct code for

maximum functionality. If some features don’t work, try

a different code. See the “Testing the Code for Maximum

Functionality” section below for more information.

During the Auto Code Search, the remote ignores

keypresses that aren’t part of the search.

The search times out after two minutes (the POWER key

blinks four times and turns off, and the last programmed

code under that device key is retained).

The POWER key blinks four times and turns off when the

remote has gone through all the codes. The remote exits

the Auto Code Search. If your device hasn’t turned off yet,

try a different search method.

Testing the Code for Maximum Functionality
1.
Try a variety of the device’s functions with the remote. If

some device features don’t work, go to the next step to try

a different code.

2. Repeat the Brand Code Search from the beginning. When

the device turns off for the first time, don’t press the STOP

key, which would store the same code. Instead, with the

unit now off, continue to press the POWER key repeatedly

until the unit turns back on.

3. Once the unit turns back on, you have found another code

that operates the device. Press the STOP key.

4. Test the key’s functionality again by attempting to control

a variety of the device’s functions. If the code that has

been stored controls the majority of the device’s functions,

programming is complete. If the code stored does not give

maximum functionality, try another code.

Brand Code Search

The Brand Code Search goes through only the codes for one of

the select brands listed in the accompanying code list. If your

brand of device is listed, this search can be very quick and easy.

TIPS: Each device key is associated with a type of device—

the TV is preset to search for TVs, SAT•CBL•DTC for satellite

receivers, cable boxes or digital TV converters, DVD•VCR

for DVD players, and DVR•AUX for DVRs. To program a

device key for a different type of device, see the Changing a

Key’s Device Type section.

To exit without saving a new code at any point in the Brand

Code Search, press the EXIT key.

1.

Manually turn on the device you

want to control.

3.

Press and hold the device key you want to program. The

POWER key illuminates.

While you’re holding down the device key, use your other

hand to press and hold the remote’s POWER key at the

same time. The POWER key turns off.

4.

Wait until the POWER key comes on

and stays on. Then release both keys.

6.

Point the remote directly at the

front panel of the device you want

to control. Press POWER on the

remote and wait 2 seconds. The

remote is testing a single code for

your device’s brand.

Did your device turn off?

YES: Press the STOP key to store the code. You’re done!

You’ve programmed this device key.

NO: Press POWER again. The remote tests the next code

for your brand.

Keep pressing POWER every 2 seconds until your device

turns off. When it does, press STOP.

2.

Find your device’s brand in the

Brand Code list section of the

accompanying code list. Circle

the number for your brand and

keep the list handy.

5.

Look at the numbers you circled for

your device’s brand code number.

Press those numbers on the remote

keypad.
Note: For single-digit brand codes,

press the 0 key first (for example, 0-5

for 5).

NOTES

Throughout the programming of each key, be sure to keep

the remote pointed at the IR sensor of the device you are

currently programming the remote to control.
Test the remote with the device to make sure the device

key is programmed with the correct code for maximum

functionality. If some features don’t work, try a different

code. See the “Testing the Code for Maximum Functionality”

section below for more information.
During the Brand Code Search, the remote ignores

keypresses that aren’t part of the search.
The search times out after two minutes (the POWER key

blinks four times and turns off, and the last programmed

code under that device key is retained).
The POWER key blinks four times and turns off when the

remote has gone through all the codes. The remote exits the

Brand Code Search. If your device hasn’t turned off yet, try a

different search method.

Direct Code Entry

Direct Code Entry lets you enter a code from the accompanying

code list for your brand of device. It’s not as easy as the other

methods, but it’s potentially the fastest method.

TIP: Each device key is associated with a type of device—

the TV is preset to search for TVs, SAT•CBL•DTC for satellite

receivers, cable boxes or digital TV converters, DVD•VCR

for DVD players, and DVR•AUX for DVRs. To program a

device key for a different type of device, see the Changing a

Key’s Device Type section.

1.

Manually turn on the device you

want to control.

3.

Press and hold the device key you want to program (the

POWER key illuminates).

While you’re holding down the device key, use your other

hand enter the first five-digit code for your brand in the

code list (the POWER key turns off after the first digit).

2.

Find the Code List that came with

the remote. Locate the section for

the type of device you’re trying to

program, and find your brand in

that section. Circle the codes for

your brand and keep them handy.

NOTES
Test the remote with the device to make sure the device

key is programmed with the correct code for maximum

functionality. If some features don’t work, try a different code

in the list.
Remember to enter the code for future reference in the box

provided in the Code Retrieval section of this manual.
If your brand isn’t listed in the code list, use one of the Code

Search methods to program the remote control. (Refer to the

Auto and Manual Code Search methods.)

If you release the device key any time during the Direct Code

Entry procedure, the POWER key blinks four times, and the

process is exited. The last programmed code under the

device key is retained.

4.

When you’ve finished entering

the five-digit code, keep holding

down the device key and look at

the POWER key.

Is the POWER key
illuminated?

YES: You’re done! You’ve programmed this device key.

NO, it blinked four times and turned off: You have

either entered a code number that is not in the code lists

or missed a step in the code entry procedure. Try step 3

again.

Manual Code Search

The Manual Code Search lets you go one-by-one through all the

codes for the device you’re trying to control. When you find the

one that operates your device, you can stop the search and store

that code.

TIPS: The Manual Code Search method may take a long time

because the remote searches through all of the codes in

its memory one-by-one. If your brand is listed in the Brand

Codes or the Code Lists, first try the Brand Code Search or

the Direct Code Entry method.

Each device key is associated with a type of device—the TV is

preset to search for TVs, SAT•CBL•DTC for satellite receivers,

cable boxes or digital TV converters, DVD•VCR for DVD

players, and DVR•AUX for DVRs. To program a device key for

a different type of device, see the Changing a Key’s Device

Type section.

To exit without saving a new code at any point in the Manual

Code Search, press the EXIT key.

1.

Manually turn on the device you

want to control.

2.

Press and hold the device key you want to program. The

POWER key illuminates

While you’re holding down the device key, use your other

hand to press and hold the remote’s POWER key at the

same time. The POWER key turns off.

3.

Wait until the remote’s POWER key

comes on and stays on. Then release

both keys.

4.

Point the remote directly at the front panel of the device you

want to control. Press POWER on the remote and wait 2

seconds. The remote is testing a single code for your device.

Did your device turn off?

YES: Press the STOP key to store

the code. You’re done! You’ve

programmed this device key.

NO: Press POWER again. The

remote tests the next code for

your device.

Keep pressing POWER every 2

seconds until your device turns off.

When it does, press STOP.

TIP: Because there are so many codes, you may have to press
the POWER key many times—possibly hundreds of times.

NOTES
Throughout the programming of each key, keep the remote

pointed at the IR sensor of the device you are programming

the remote to control.
Test the remote with the device to make sure the device

key is programmed with the correct code for maximum

functionality. If some features don’t work, try a different

code. See the “Testing the Code for Maximum Functionality”

section below for more information.
During the Manual Code Search, the remote ignores

keypresses that aren’t part of the search.
The search times out after two minutes (the POWER key

blinks four times and turns off, and the last programmed

code under that device key is retained).
The POWER key blinks four times and turns off when the

remote has gone through all the codes. The remote exits the

Brand Code Search. If your device hasn’t turned off yet, try a

different search method.

Testing the Code for Maximum Functionality
1.
Try a variety of the device’s functions with the remote. If

some features of your devices don’t work, go to the next

step to try a different code.

2. Repeat the Manual Code Search and Entry Method from

the beginning. When the device turns off for the first time,

don’t press the STOP key, which would store the same

code. Instead, with the unit now off, continue to press the

POWER key repeatedly until the unit turns back on.

3.

Once the unit turns back on, you have found another code

that operates the device. Press the STOP key.

4. Test the key’s functionality again by trying a variety of

functions. If the code controls the majority of the device’s

functions, programming is complete. If the code stored

does not give maximum functionality, try another code.

Changing A Key’s Device Type

Each device key is associated with a type of device—the TV is

preset to search for TVs, SAT•CBL•DTC for satellite receivers,

cable boxes or digital TV converters, DVD•VCR for DVD players or

VCRs, and DVR•AUX for DVRs. To program these keys to control a

different kind of device, you have to reassign them first.

Reassigning the DVD•VCR Key to Control a VCR
The DVD•VCR key defaults to control a DVD player. If you want

the DVD•VCR key to control a VCR, you must reassign it.
1. Press and hold the DVD•VCR key. The POWER key

illuminates. Keep holding down the DVD•VCR key.

2. While holding down the DVD•VCR key, press and release

the number 2 key on the keypad. The POWER key turns off.

3. Release the DVD•VCR key. The POWER key blinks four times

and then turns off. The DVD•VCR key is now set to control a

VCR.

4. Follow the directions in the auto, brand, direct entry, or manual

code search to program the DVD•VCR key for your VCR.

Reassigning the DVR•AUX Key To Control Other
Devices
The DVR•AUX key defaults to control a DVR. If you want the

DVR•AUX key to control a different device (an additional TV,

DVD, satellite or cable box, for example), you must reassign it.
1. Press and hold the DVR•AUX key. The POWER key turns

on.

2. While holding down the DVR•AUX key, press and release the

number key on the keypad for the device you wish to control

(see the chart below). The POWER key turns off.

Code Retrieval

Once you’ve programmed the remote to control your devices,

you may want to record the codes for future reference. If you

used the Direct Code Entry method, this is easy. Just find

the codes you entered and make a note of them in the boxes

below. If you used one of the Code Search methods to program

your remote or if you used the Direct Entry method but don’t

remember the code, you will need to retrieve each device’s

five-digit code. Retrieving the actual code and writing it down

will save you time if you ever need to program the remote

again. If the codes are recorded, you can use the Direct Entry

method to reprogram your remote to control your devices,

which is quick and easy.

1. Press and hold the device key

(TV, SAT•CBL•DTC, DVD•VCR,

DVR•AUX) whose code you wish

to retrieve. The POWER key

illuminates. Keep pressing the

device key.

2. While holding the device key down, press and hold the

INFO key. The POWER key turns off. After holding down

both keys for three seconds, the POWER key turns back on.

3. Release both keys. The POWER key remains on.
4. Starting with the number 1 key, press and release each

number key on the keypad in the following order: 1-9, then

0. The number that causes the POWER key to blink is the

first number of the code. As you find each number of the

code, write it down for future reference.

Note: All TV codes begin with the number 1; all VCR and DVR

codes begin with the number 2; all DVDs, the number 3; and

all satellite receivers, cable boxes and DTV converters, the

number 5.

5. Repeat step 4 until you have retrieved all five numbers in

the code. After the fifth number is retrieved, the POWER

key blinks briefly, then turns off.

TIP: To exit the Code Retrieval Mode at any time, press the

EXIT key.
Note: If you press an invalid key during the Code Retrieval

process, the remote will not respond. If you do not press

a valid Code Retrieval key (TV, SAT•CBL•DTC, DVD•VCR,

DVR•AUX, INFO, EXIT), Code Retrieval times out after 15

seconds. The POWER key blinks four times, and then turns

off.

IMPORTANT

Because this remote controls more than one device, you

must first “tell” the remote which device you wish to

operate. That means, if you wish to operate your TV, you

must first press the TV key to put the remote in the TV

Mode. The remote stays in that device mode until you press

a different device key. For example, if your remote is in TV

Mode and you want to operate the DVD player, you must

press the DVD•VCR key to change device modes.

Problem: The remote does not operate your device.

Make sure the remote is in the correct mode by pressing

the corresponding device key (TV, SAT•CBL•DTC, DVD•VCR,

DVR•AUX). This tells the remote which device to operate.

Remove any obstacles between the remote and the device. Make

sure you’re aiming the remote at the device’s IR sensor.

Make sure the batteries are fresh and are properly installed.

Replace the batteries with two new AAA batteries, if necessary

(see the Battery Installation section).

Problem: The remote can’t be programmed to operate your

device.

If you are testing the remote while programming it, you may be

too far away from the device or at a wrong angle. There must be

an unobstructed path between the remote and the IR sensor on

the device. Move closer and make sure you point the remote at the

device you’re trying to control.

If you’re using the Direct Entry programming method to enter

the codes for your brand and the unit is still not functioning

properly, try the auto, brand, or manual search method.

To control combo units, like TV/VCRs or TV/DVDs, you must

program the individual corresponding device keys to control

each part of the combo unit. Once programmed successfully, the

TV key controls the TV functions, and the DVD•VCR key controls

the VCR or DVD functions.

Make sure the batteries are fresh and are properly installed.

Problem: The remote doesn’t perform commands properly.

Make sure the remote is in the correct mode by pressing

the corresponding device key (TV, SAT•CBL•DTC, DVD•VCR,

DVR•AUX). This tells the remote which device to operate.

Make sure device is ready (for example, the DVD player has a

disc loaded).

You may have pressed an invalid key for the mode the remote is in.

If you’re trying to enter a channel number directly, try pressing

the ENTER key after entering the channel number as this is a

requirement of certain models and brands.

There is a possibility that a programmed code may only be

able to control some of your device features (for example, only

turns a device on and off). To confirm that the device key is

programmed with the correct code for maximum functionality,

test the device. Attempt to control a variety of the device’s

functions with the remote. If some of the features of your

devices don’t work, try programming the remote with a different

code in the list using the Direct Code Entry Method, until you

find the code that allows the remote to control the majority of

your device’s functions. Different codes can provide different

levels of functionality.

Problem: The POWER key does not light when you press a key.

You may have pressed an invalid key for the mode the remote is in.

Make sure the remote is in the correct mode by pressing

the corresponding device key (TV, SAT•CBL•DTC, DVD•VCR,

DVR•AUX). This tells the remote which device to operate.

Make sure the batteries are fresh and are properly installed.

Replace the batteries with two new AAA batteries, if necessary

(see the Battery Installation section).

Problem: The remote will not change channels on device.

Make sure the remote is in the correct mode by pressing

the corresponding device key (TV, SAT•CBL•DTC, DVD•VCR,

DVR•AUX). This tells the remote which device to operate.

Press the ENTER key after you enter a channel number.

Remove any obstacles between the remote and the device. Make

sure to aim the remote at the IR sensor on the device.

Problem: The device’s menu does not appear on the TV screen.

Make sure you have connected the device to your TV properly and

selected the correct input. (See your devices’ Owner’s Manuals for

proper connection procedures.)

Make sure the remote is in the correct mode by pressing

the corresponding device key (TV, SAT•CBL•DTC, DVD•VCR,

DVR•AUX). This tells the remote which device to operate.

Menu access isn’t supported for all brands. You may need to use

your original remote control to access menu functions for some

devices.

For more information, please visit www rcaaccessories.com
Consumer Help Line: 1-800-420-7968

Audiovox Electronics Corporation (the “Company”) warrants to you the

original retail purchaser of this product that should it, under normal use

and conditions, be proven defective in material or workmanship during

its lifetime while you own it, such defect(s) will be repaired or replaced

(at the Company’s option) without charge for parts and repair labor. To

obtain repair or replacement within the terms of this Warranty, the product

is to be delivered with proof of warranty coverage (e.g. dated bill of sale),

specification of defect(s), transportation prepaid, to the Company at the

address shown below.
This Warranty does not cover product purchased, serviced or used outside

the United States or Canada. This Warranty is not transferable and does

not extend to costs incurred for installation, removal or reinstallation of

the product. This Warranty does not apply if in the Company’s opinion,

the product has been damaged through alteration, improper installation,

mishandling, misuse, neglect, accident, or the simultaneous use of different

battery types (e.g. alkaline, standard or rechargeable).
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS

LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO

EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE

PAID BY PURCHASER FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY

IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL

BE LIMITED TO DURATION OF THIS WARRANTY. IN NO CASE SHALL

THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL

DAMAGES WHATSOEVER. No person or representative is authorized

to assume for the Company any liability other than expressed herein in

connection with the sale of this product.
Some states/provinces do not allow limitations on how long an implied

warranty lasts or the exclusion or limitation of incidental or consequential

damage so the above limitations or exclusions may not apply to you. This

Warranty gives you specific legal rights and you may also have other rights,

which vary from state/province to state/province.
U.S.A.: Audiovox Electronics Corporation, 150 Marcus Blvd., Hauppauge,

New York 11788

CANADA: Audiovox Return Center, c/o Genco, 6685 Kennedy Road,

Unit 3, Door 16, Mississauga, Ontario L5T 3A5

Trademark(s) ® Registered

RCRN04GR US 00

©2010 Audiovox Accessories Corporation

Step 1: Install your batteries

Step 2: Program your remote

Tour of the Remote

Advanced Functions

Troubleshooting

Limited Lifetime Warranty

DVR•AUX KEY CONTROLS:

Additional TV

press 1

VCR or DVR

press 2

Additional DVD

press 3

Additional satellite, cable box or

digital TV converter

press 5

3. Release the DVR•AUX key. The POWER key blinks four

times and then turns off. The DVR•AUX key is now set to

control the device type you selected.

4. Follow the directions in the auto, brand, direct entry, or

manual code search to program the DVR•AUX key.

DVD•VCR CoDe

DVR•AUX CoDe

5

SAT•CBL•DTC CoDe

1

TV CoDe

SAT

CABLE

dTv ConvErTEr

dvd

vCr

dvr/vCr

dvd

Tv

SAT•CBL•DTC

Volume Punch-Through

Volume punch-through allows the VOL and MUTE keys, when

pressed in SAT•CBL•DTC, DVD•VCR, or DVR•AUX modes,

to “punch through” to TV. Volume punch-through occurs

automatically and allows you to control the volume without

exiting the current mode. (If the DVR•AUX key has been

programmed with a TV code, volume can punch through to

this device as well.)
Note: Volume punch-through does not occur in cases where

the component code has its own volume/mute controls, such

as some satellite receivers.

Transport Key Punch-Through

Transport key punch-through allows the transport keys (REVERSE,

PLAY, FORWARD, RECORD, STOP, PAUSE, SKIP BACK, SLOW,

and SKIP FWD), when pressed in TV or SAT•CBL•DTC modes, to

“punch through” to DVD•VCR or DVR•AUX mode, whichever was

accessed last. Transport key punch-through occurs automatically

and allows you to use the transport keys without exiting the

current mode. For example, if the transport keys were last used in

DVD mode and accessed again after pressing the TV key, they will

punch through to the DVD.
Note: Transport key punch-through does not occur in cases

where the device code has its own transport key data, such as

a satellite receiver with a built-in DVR.

Channel Lock

Channel lock automatically sends channel commands, like the

CH, GO BACK, and 0–9 number keys, to your satellite receiver,

cable box, or digital TV converter when you’re in TV mode.

This can save you keypresses if you use a device other than

your TV to change channels.
To turn channel lock on:
1.

Press and hold the device key for the device you use to

change channels. While you’re holding down this device

key, use your other hand to press and hold the remote’s

CH up key at the same time.

2. Wait until the remote’s POWER key comes on and stays on.

Then release both keys.

3. Press ENTER to lock channel commands to this device.

To turn channel lock off:
1.

Press and hold the TV key. While you’re holding down the

TV key, use your other hand to press and hold the remote’s

CH down key at the same time.

2. Wait until the remote’s POWER key comes on and stays on.

Then release both keys.

3. Press ENTER to start changing channels with your TV.

Cod

e Li

sts

/

Liste

des

codes

/

List

a d

e C

ódi

gos

rand

Co

e i

t

ste

es

ode

de

ma

que

/

L ta

e C

dig

s de

Ma

as

Cod

e Li

sts

/

Liste

des

codes

/

List

a d

e C

ódi

gos

r nd

o e

L t

/

s e

es

o e

de

m rque

/

L s a

e C

d g

s e

Ma

as
