31
SPECIFICATIONS
AMPLIFIER SECTION
Output Power (Front) 60 watts RMS per channel minimum**
Surround Output Power 40 + 40 Watt (Front)
(0.5% THD, 1 kHz, 8Ω) 40 Watt (Center)
40 + 40 Watt (Rear)
Total Harmonic Distortion (Front) 0.02 % (at 60 watts, 1 kHz)
Delay Time DOLBY DIGITAL & DTS REAR 0 - 15 ms
CENTER 0 - 5 ms
DOLBY PRO LOGIC II MOVIE & EMULATION REAR 10 - 25 ms
DOLBY PRO LOGIC II MUSIC REAR 0 - 15 ms
Audio Input Sensitivity/Impedance (LINE*) 200 mV/47 k ohms
Output Level / Impedance (TAPE REC) 185 mV/2.2 k ohms
Frequency Response (LINE*) 20 Hz - 65 kHz, +1/ -3 dB
Signal-to-Noise Ratio : 1 Watt (LINE*) 70 dB (IHF-A)
Tone Control BASS ±10 dB at 100 Hz
TREBLE ±10 dB at 10 kHz
DIGITAL AUDIO SECTION
Sampling Frequency 32 kHz, 44.1 kHz, 48 kHz
DIGITAL Input Level/Impedance COAXIAL 0.5 Vp-p/75 ohms
OPTICAL -15 dBm ~ -21 dBm
VIDEO SECTION
Input Sensitivity /Impedance 1.0 Vp-p/75 ohms
Output Level /Impedance 1.0 Vp-p/75 ohms
FM TUNER SECTION
Tuning Range : 87.5 MHz - 108.0 MHz 50 kHz steps
AM Suppression Ratio: 45 dB
Total Harmonic Distortion (1 kHz) Mono : 0.4%
Stereo : 0.5%
Frequency Responses 30 Hz - 15 kHz, +1/ -1. 5 dB
Stereo Separation (1 kHz) 40 dB
Signal-to-Noise Ratio Mono : 75 dB
Stereo : 70 dB
AM TUNER SECTION
Tuning Range 522 kHz - 1,620 kHz (9 kHz steps)
Usable Sensitivity 55 dB/m
Total Harmonic Distortion 0.8% at 85 dB/m
Signal-to-Noise Ratio 45 dB at 85 dB/m
GENERAL
Power Requirements 230V AC, 50Hz
Power Consumption 1.2A
Dimensions (W x H x D) 285 x 133 x 348
Weight (net) 8.8kg
* LINE means TAPE, AUX, VIDEO 1, VIDEO 2, DVD
** both channels driven into 8 ohms from 20 Hz to 20kHz with no more than 0.09% total harmonic distortion
Improvements may result in specifications and features changing without notice
Illustrations may differ from production models.
