Chapter 3 Software Overview
NI-VXI User Manual 3-12 © National Instruments Corporation
Normally, you would use the WSLcmd function to send Longword
Serial queries with the response automatically read (specified with
respflag). In cases when you need to inspect the Longword Serial
transfer at a lower level, however, you can break up the query sending
and query response retrieval by using the
WSLcmd function to send the
query as a command, and using the WSLresp function to retrieve the
response. WSLresp polls the RR bit before reading the response from
the Data High and Data Low registers to form the 32-bit response.
After reading the response, it polls the Response register until the WR
bit is asserted to guarantee that no protocol errors occurred during the
transfer.
WSrd (la, buf, count, modevalue, retcount)
WSrd is the word serial buffer read function. WSrd reads a specified
number of bytes from a Servant device into a local memory buffer,
using the VXIbus Byte Transfer Protocol. The process involves
sending a series of Byte Request (BREQ) Word Serial queries and
reading the responses. Each response contains a data byte in the lower
8 bits and the END bit in bit 8. Before sending the BREQ command,
WSrd polls both Response register bits—Data Out Ready (DOR) and
Write Ready (WR). It polls the Response register Read Ready (RR) bit
before reading the response from the Data Low register. The read
terminates when it receives a maximum number of bytes or if it
encounters an END bit, a carriage return (CR), a line feed (LF), or a
user-specified termination character.
WSrdf (la, filename, count, modevalue, retcount)
WSrdf is an extension of the WSrd function. WSrdf reads a specified
number of bytes from a Servant device into the specified file, using the
VXIbus Byte Transfer Protocol. The process involves calling the
function
WSrd (possibly many times) to read in a block of data and
writing the data to the specified file. The read terminates when it
receives a maximum number of bytes or if it encounters an END bit, a
carriage return (CR), a line feed (LF), or a user-specified termination
character.
WSresp (la, response)
WSresp retrieves a response to a previously sent Word Serial Protocol
query from a VXI message-based Servant.
Note: This function is intended only for debugging purposes.
