Page 5-10 NDA-24230 Issue 2.0
Chapter 5 VisuaLink 128/384 User Guide
➂ Press the CALLPAGE button to proceed to the AUDIO LEVEL PAGE.
➃ Press ENTER button to define it after changing a setting.
➄ Press the MENU or CANCEL button three (3) times to proceed back to the
video image.
- 36 -30 -24 -18 -12 -6 0 +6
[dB]
SEND:
RECEIVE:
MIC/headset gain : <04>
Audio/TEL gain : <00>
Volume:<08> Operation:
Test Tone : Training:
Camera Moving
Level: <3>
Condition: _ _ _
Previous page: CALL PAGE
Please select an item and adjust with <–>.
Level bar for incoming and
outgoing audio
Sets the outgoing audio
level for the headset and
MIC
Sets the outgoing audio
level for the telephone and
audio input
Status message for audio
test tone
Status bar for the
microphone:
1 2 3
MIC1 MIC2 MIC3
Sets the default volume
setting
Allows for activating or
deactivating audio tone
Camera audio preset level
Setting 0 1 2 3 4 5 6 7
dB [level] -36 -33 -30 -27 -24 -21 -18 -15
