NDA-24230 Issue 2.0 Page 5-1
VisuaLink 128/384 User Guide Chapter 5
Chapter 5 System Parameter/Environment Setting
System parameter sets the operation conditions of the VisuaLink 128 or
VisuaLink 384. Environment setting can be set such as camera class, audio
related, data related, line related and local office status. Loopback feature can be
used as a maintenance feature.
Note 1: Make system parameter changes when the system is not connected.
Note 2: Depending on the setting for audio, data speed and bit rate, and the video
has the possibility for not being transmitted. Please refer to Appendix A:
Audio/Data/Video Bit Rate Assignment Table for bit rate assignment of
audio, data, video bit rate.
5.1 Environment
Setting Menu
5.1.1 Set an environment
① Press the MENU button to display the MAIN MENU.
▲
Setting the PIP parameter.
MENU
