Bale Wagon Specifications
H9870 H9880 1037
Page 2 of 2
MODEL NUMBER H9870 H9880 1037
Operating speeds, mph (kph)
Loading 10 (16) 10 (16) NA
Hauling (on approved grounds) 30 (48) 30 (48) NA
Hydraulic pumps Piston pump Piston pump 10.5 gpm (39.7 Lpm)
29 gpm (110 Lpm) 29 gpm (110 Lpm)
@ 2450 rpm (2050 psi) @ 2450 rpm (2050 psi)
Gear pump Gear pump
6.7 gpm (25 Lpm) 6.7 gpm (25 Lpm)
@ 2450 rpm @ 2450 rpm
Gear pump Gear pump
13.8 gpm (52 Lpm) 13.8 gpm (52 Lpm)
@ 2450 rpm @ 2450 rpm
Hydraulic valves Electro-hydraulic Electro-hydraulic Manual spool valve
Two manifold valve Two manifold valve
assemblies assemblies
Bale length, in. (cm)
Minimum 36 (91) 44 (118) 34 (86)
Maximum 41 (104) 48 (122) 42 (106)
Stack size, in. (cm)
16 x 18, height 162 (411) 162 (411) 7 tiers
16 x 18, width 120 (305) 92 (234) 3 bales
14 x 18, height 162 (411) NA 7 tiers
14 x 18, width 114 (290) NA 3 bales
16 x 23, height NA 151 (384) NA
16 x 23, width NA 92 (234) NA
15 x 22, height NA 157 (399) NA
15 x 22, width NA 92 (234) NA
Automatic tie tier Standard Standard NA
Max. hillside angle NA NA 10°
OPTIONS
■ Heater ■ Heater ■ Hillside hauling kit
■ Weight box ■ Weight box ■ Tractor-mounted
■ Wiper kit ■ Wiper kit remote controls
■ Radio ■ Radio ■ Tier counter
■ Fan reverser ■ Fan reverser
■ First table flow control valve ■ First table flow control valve
■ Auxiliary mirror ■ Auxiliary table flow control valve
■ Rear worklight ■ 16 x 18 bale kit
■ Brake pedal kit ■ Auxiliary mirror
■ Rear worklight
■ Brake pedal kit
Safety begins with a thorough understanding of
the equipment. Always make sure you and
your operators read the Operator’s Manual
before using the equipment. Pay close
attention to all safety and operating
decals and never operate machiner y
without all shields, protective devices
and structures in place.
Design, materials and/or specifications are subject to
change without notice and without liability therefor.
Specifications are applicable to units sold in Canada, the
United States, its territories and possessions, and may
var y outside these areas.
