Chapter 3 Installing the shelf, OADM, and OMUX
212257-B
Removing a CWDM OADM or a CWDM OMUX
CWDM OADMs and CWDM OMUXs are passive devices that require no power
for their operation. You can remove them from the optical shelf (
) after
disconnecting them from your network.
To remove a CWDM OADM or a CWDM OMUX plug-in module from the
optical shelf:
1
Disconnect the network cabling from the multiplexer.
2
Loosen the captive screws on both sides of the module.
3
To release the module, gently pull on both screws at the same time.
4
Slide the module out of the shelf
.
