Page 25
Chapter 1 Describing the optical routing system
25
Installation and Networking Guidelines for Optical Routing
Figure 10 CWDM OMUX ring configuration example
For information about calculating network transmission distance, see
“Calculating transmission distance,” on page 27
.
OADM
OMUX
OMUX
OFFICE
BUILDING B
OADM
OADM
PP 8600
PP 8600
OFFICE
BUILDING C
PP 8600
OFFICE
BUILDING A
10326EA
CARRIER
HOTEL SITE
PP 8600
PP 8600
