22 Chapter 1 Describing the optical routing system
212257-B
Figure 6 Four-channel CWDM OMUX front panel
Connectors with color-coded labels ( Table 1 ) simplify connection to color-coded
CWDM GBICs in the switch.
CWDM OMUX-4
Figure 7 shows the CWDM OMUX-4 version, with four CWDM GBIC
equipment side connections.
Figure 7 CWDM OMUX-4 network and equipment side connections
CWDM OMUX-8
Figure 8 shows the CWDM OMUX-8 version, with eight CWDM GBIC
equipment side connections.
T
o
Ne
twork
To Equipment side CWDM GBICs
RX
TX
RX TX RX TX RX TX RX TX
CWDM OMUX-4
