Timing Chart
Y/N
Signal
Resolution
Refresh
F.H.
Dot
Rate (Hz)
(kHz)
Clk(MHz)
Y
NTSC
640
ן480
60
15.734
-
Y
PAL
768
ן576
50
15.625
-
Y
SECAM
768
ן576
50
15.625
-
Y
VESA
640
ן350
85.08
37.86
31.5
Y
IBM
640
ן400
70
31.47
25.175
Y
VESA
640
ן400
85.08
37.86
31.5
Y
MAC
640
ן400
66
35
30.24
Y
VESA
640
ן480
59.94
31.47
25.175
Y
IBM
640
ן480
60
31.47
25.175
Y
MAC
640
ן480
60
31.47
25.175
Y
MAC
640
ן480
66.7
34.97
31.334
Y
MAC
640
ן480
66.67
35
30.24
Y
VESA
640
ן480
72.81
37.86
31.5
Y
VESA
640
ן480
75
37.5
31.5
Y
IBM
640
ן480
75
39.375
31.49
Y
VESA
640
ן480
85.01
43.269
36
Y
IBM
720
ן350
70.09
31.469
28.322
81
Y
IBM
720
ן400
70.09
31.4469
28.322
Y
VESA
720
ן400
85.04
37.927
40
Y
IBM
720
ן350
87.85
39.44
35.5
Y
IBM
720
ן400
87.7
39.375
35.5
Y
VESA
800
ן600
56.25
35.16
36
Y
VESA
800
ן600
60.32
37.879
40
Y
VESA
800
ן600
72.19
48.077
50
Y
VESA
800
ן600
75
46.88
49.5
Y
VESA
800
ן600
85.06
53.674
56.25
#
MAC
832
ן624
74.55
49.725
57.283
N
VESA
1024
ן768
43interlace
35.5
44.9
#
VESA
1024
ן768
60
48.363
65
#
VESA
1024
ן768
70.07
57.476
75
#
IBM
1024
ן768
72.03
58.131
79
#
MAC
1024
ן768
74.93
60.241
80
#
VESA
1024
ן768
75.03
60.023
78.75
N
VESA
1024
ן768
85
68.677
94.5
Incompatible signals are marked with on "N" and hatched. # 1024x768 and 832x624 images
are compressed into 800x600.
