NetComm HSPA 7.2 MBPS WI-FI ROUTER 3G9W - Manual (Page 34)

34 – YML902
5.6 Station Info
The following screen appears when you select Station Info, and shows authenticated wireless stations and
their status.
Click the
Refresh button to update the list of stations in the WLAN.
BSSID The BSSID is a 48-bit identity used to identify a particular BSS (Basic Service Set) within
an area. In Infrastructure BSS networks, the BSSID is the MAC (Media Access Control)
address of the AP (Access Point); and in Independent BSS or ad hoc networks, the BSSID
is generated randomly.
Associated Lists all the stations that are associated with the Access Point, along with the amount of
time since packets were transferred to and from each station. If a station is idle for too
long, it is removed from this list.
Authorized Lists those devices with authorized access.
