3G9W - HSPA 7.2Mbps Wi-Fi Router USER GUIDE

YML902 – 15

3.3

To login to the web interface, follow the steps below:

NOTE:

The default settings can be found in 3.1 Default Settings.

1: Open a web browser and enter the default IP address for the Router in the Web address field. In this case

http://192.168.1.1.

NOTE:

For local administration (i.e. LAN access), the PC running the browser must be attached to the Ethernet, and not necessarily to the
device. For remote access, use the WAN IP address shown on the WUI Homepage screen and login with remote username and
password.

2: A dialog box will appear, as illutstrated below. Enter the default username and password, as defined in

section 3.1 Default Settings.

Click OK to continue.

NOTE:

The login password can be changed later (see 7.3.3 Passwords)

3: After successfully logging in for the first time, you will reach this screen.
