Niles Audio SI-1260 - Manual (Page 31)

SPECIFICATIONS
Design Principle
Linear voltage/current amplification.
Continuous Power Output (FTC Rated)
(Unbridged, all channels driven) 60 watts per channel at 8 ohms, 80 watts per
channel at 4 ohms.
Bridged Power Output
(Adjacent channels bridged, all channels driven) 120 watts per channel at
8 ohms.
Input Impedance
47,000 ohms
Input Sensitivity
100mv for 1 watt out; 850mv for full output, (60 watts) level controls set at maximum.
Overall Voltage Gain
29 dB
Frequency Response
Bandwidth from 5 Hz to 50 kHz
Distortion
(Normal mode)
0.06% THD 20Hz to 20kHz all channels driven (8 ohms)
0.06% THD rated 20Hz to 20kHz all channels driven (4 ohms)
(Bridged mode)
0.06% THD 20Hz to 20kHz all channels driven (8 ohms)
Overall Dimensions
17 inches wide by 7.375 inches high (including feet) by 15 inches deep.
Weight
70 pounds
