Specifications Appendix B
GPIB-120A User Manual B-2 © National Instruments Corporation
Table B-3. Electrical Characteristics
Characteristic Specification
Isolation 60 V operating
1600 V breakdown
Power supply selectable 90 to 130 VAC, 235 mA, (250 mA, 250 V,
slow blow), 50 to 60 Hz or
180 to 260 VAC, 120 mA, (200 mA,
250 V, slow blow), 50 to 60 Hz
GPIB interface load One standard load, AC and DC
Power 27 VA typical
Table B-4. Environmental Characteristics
Characteristic Specification
Operating temperature 0
°
to 45
°
C
Humidity 5% to 95% noncondensing conditions
EMI FCC Class A Verified
Table B-5. Physical Characteristics
Characteristic Specification
Case style CS2
Case size 89 mm by 216 mm by 330 mm
(3.5 in. by 8.5 in. by 13 in.)
Case material UL94V-0 flame retardant polystyrene
DOW 60875F or Noryl FN-215
