Chapter 2 Hardware Installation
NI ExpressCard MXI Series User Manual 2-4 ni.com
If your computer is already running (or hibernating, etc.) when you
install NI ExpressCard MXI, you must reboot to detect the PXI system.
Otherwise, the PXI system is detected when you start your computer.
Figure 2-2 shows how to insert the NI ExpressCard-8360 and connect the
cable.
Figure 2-2. Installing the NI ExpressCard-8360
Cabling
The NI ExpressCard MXI interface uses the same cable as MXI-Express
and MXI-Express for PXI Express. The cables have no polarity, so either
end may be connected to either board.
Caution Do not remove the cable after the system is powered on. Doing so can hang
or cause errors in applications communicating with devices behind NI ExpressCard MXI.
If a cable becomes unplugged, plug it back into the system.
1 MXI-Express Cable 2 ExpressCard Slot 3 Portable Computer
3
2
1
