Home Worker
Non-Meridian 1 PABX Users
Meridian 1 PABX Users
Internet
i2050 IP
Soft Phone
Contivity
VPN Switch
Business
Communications
Manager
Voice
Voice
PSTN
PSTN
PBX
LAN
Contivity VPN
Switch
Meridian 1
with ITG
Users Database
Broadband
access
Contivity
IPSec Client
Home workers have VPN access with office PABX connectivity
i2004 IP
Phone
TDM IP
IPSec Tunnels
TDM IP
The Nortel Networks Home Worker solution is built
from a range of IP-capable products. Secure access
into the corporate LAN is provided by the Contivity
suite of VPN switches. Contivity integrates all of the
elements needed to build a high performance,
scalable and secure VPN – routing, firewall,
bandwidth management, encryption,
authentication and data integrity – into one single
platform for secured tunnelling across the Internet.
Home-side telephony is provided by the
Nortel Networks suite of IP telephony solutions,
including the i2050 Soft Client (can be used with a
USB headset), USB phones that connect into the PC
and the i2004 IP phone.
In the office, Enterprises can leverage the evolution
of their existing Meridian-1 PABX solutions by
adding a line-side ITG (Internet Telephony Gateway)
card to enable connectivity of IP clients to the PABX.
For non-Meridian-1 users, a Business
Home Worker Solution 219
Secure Remote Connectivity
Home Worker Solution
Customer Needs
• Extend coverage of LAN and phone network to home users
• Provide secure high performance access to home users via any IP transport
• Extend PABX dialling plan to remote users
• Provide in-office phone functionality to home users
• Enable home-worker calls to be made on internal network (carrier arbitrage)
Nortel Networks Solution
Business Connectivity via the Internet
