Chapter 2 Setup and Configuration
NI CVS-1450 Series User Manual 2-6 ni.com
Examples of Installation Category II are measurements performed on
household appliances, portable tools, and similar products.
• Measurement Category III is for measurement performed in the
building installation at the distribution level. This category refers to
measurements on hard-wired equipment such as equipment in fixed
installations, distribution boards, and circuit breakers. Other examples
are wiring, including cables, bus-bars, junction boxes, switches,
socket-outlets in the fixed installation, and stationary motors with
permanent connections to fixed installations.
• Measurement Category IV is for measurements performed at the
primary electrical supply installation (<1,000 V). Examples include
electricity meters and measurements on primary overcurrent
protection devices and on ripple control units.
Setup Overview
Figure 2-1 illustrates the sequence for setting up and getting started with
the CVS-1450 device.
Figure 2-1. Setup Sequence
or
or
Set Up the Development
Computer Using
Vision Builder AI
Set Up the Development
Computer Using LabVIEW
Real-Time with the Vision
Development Module
Acquire an Image Using
Vision Builder AI
Acquire an Image Using
LabVIEW Real-Time with the
Vision Development Module
Set Up the Hardware
