36 Chapter 3 Installing the Passport 8250 device
241-5101-200 R2.2
Exit and secure all cables to the left as illustrated in “Cables left of chassis”
(page 36) or underneath the chassis as illustrated in “Cables underneath
chassis” (page 36).
Figure 8
Cables left of chassis
Figure 9
Cables underneath chassis
