New Holland G5000 Series Commercial
Zero-Turn-Radius Mowers Specifications
G5030 G5035
Page 2 of 2
MODEL G5030 G5035
MOWER DECK
Deck Size
54 inch 60 inch 66 inch
Mower deck overall width, in. (mm) 55.5 (1410) 61.8 (1570) 67.7 (1720)
Cutting width, in. (mm) 54.0 (1372) 60.0 (1524) 66.0 (1676)
Blade length, in. (mm) 19 (482.6) 21 (533.4) 23 (584.2)
Deck weight*, lbs. (kg) 272 (123) 297 (125) 313 (142)
Tip speed at 3600 rpm, fpm. (km/h) 18,867 (345.0) 17,630 (322.4) 18,413 (336.7)
Style ........................................................................................................................................High volume full flow tunnel deck...............................................................................
Steel thickness..................................................................................................................7 Gauge, grade 50 - welded construction.........................................................................
Deck lift........................................................................................................................................Foot operated spring assist....................................................................................
HOC adjustment...........................................................................................................................Fingertip control dial gauge....................................................................................
Number of blades .............................................................................................................................................3 ........................................................................................................
Blade thickness, in. (mm) .......................................................................................................................0.203 (5.16) ...............................................................................................
Cutting height, in. (mm) ................................................................................................................1.0 to 6.0 (25.4 - 152.4) ......................................................................................
Depth, in. (mm) .............................................................................................................................5.5 to 7.75 (14.0 - 19.7) ......................................................................................
OTHER
Arm rests....................................................................................................................................................Standard ..................................................................................................
Hitch..............................................................................................................................................Rated for towing <250 lb. ....................................................................................
Seat ....................................................................................................18” high back w/ custom suspension - adjusts to wt. of rider; 150 lb - 250 lb. ...........................................
WARRANTY ............................................................................................................................................2 year limited...............................................................................................
*Add unit, ROPS and applicable deck weight for total mower weight.
**With deck in the transport position.
Safety begins with a thorough understanding of
the equipment. Always make sure you and
your operators read the Operator’s Manual
before using the equipment. Pay close
attention to all safety and operating
decals and never operate machiner y
without all shields, protective devices
and structures in place.
Design, materials and/or specifications are subject to
change without notice and without liability therefor.
Specifications are applicable to units sold in Canada, the
United States, its territories and possessions, and may
var y outside these areas.
© 2009 CNH America LLC
New Holland is a registered trademark of CNH America LLC.
Visit our Web site at www.newholland.com/na. Or, call toll-free 866-NEW-HLND (866-639-4563).
