NI 9264 Operating Instructions and Specifications 12 ni.com
Specifications
The following specifications are typical for the range –40 to 70 °C
unless otherwise noted. All voltages are relative to COM unless
otherwise noted.
Output Characteristics
Number of channels.......................... 16 analog output channels
DAC resolution ................................. 16 bits
Type of DAC ..................................... String
Output range
Minimum.................................... ±10.35 V
Typical ........................................ ±10.5 V
Maximum ................................... ±10.65 V
Current drive ..................................... ±16 mA all channels max;
±4 mA per channel typ
Power-on output state ....................... Channels off
Startup voltage .................................. 0 V 1
1 When the module powers on, a glitch occurs for 20 μs peaking at 500 mV.
