Appendix A Specifications
NI 783xR User Manual A-4 ni.com
Accuracy Information
DC Transfer Characteristics
INL
..........................................................±0.5 LSB typ, ±4.0 LSB max
DNL
........................................................±0.5 LSB typ, ±1 LSB max
Monotonicity ..........................................16 bits, guaranteed
Voltage Output
Range
......................................................±10 V
Output coupling ......................................DC
Output impedance...................................1.25
Ω
Current drive
...........................................±2.5 mA
Protection................................................Short-circuit to ground
Power-on state ........................................User configurable
Dynamic Characteristics
Settling time
Nominal Range (V)
Absolute Accuracy
Absolute
Accuracy at
Full Scale
(mV)
% of Reading
Offset ( µ V)
Temp Drift
(%/°C)
Positive Full
Scale
Negative Full
Scale 24 Hours 1 Year
10.0 –10.0 0.0335 0.0351 2366 0.0005 5.88
Note: Accuracies are valid for analog output following an internal calibration. Analog output accuracies are listed for
operation temperatures within
±
1 °C of internal calibration temperature and
±
10 °C of external or factory calibration
temperature. Temp Drift applies only if ambient is greater than
±
10 °C of previous external calibration.
Step Size
Accuracy
16 LSB 4 LSB 2 LSB
±20.0 V
6.0 µ s 6.2 µ s 7.2 µ s
±2.0 V
2.2 µ s 2.9 µ s 3.8 µ s
±0.2 V
1.5 µ s 2.6 µ s 3.6 µ s
