Chapter 1 Introduction
NI 783xR User Manual 1-8 ni.com
Refer to Appendix B, Connecting I/O Signals , for more information about
using these cables and accessories to connect I/O signals to the NI 783xR.
Refer to
ni.com/products or contact the sales office nearest to you for
the most current cabling options.
Custom Cabling
NI offers a variety of cables for connecting signals to the NI 783xR. If you
need to develop a custom cable, a nonterminated shielded cable is available
from NI. The SHC68-NT-S connects to the NI 783xR VHDCI connectors
on one end of the cable. The other end of the cable is not terminated. This
cable ships with a wire list identifying the wires that correspond to each
NI 783xR pin. Using this cable, you can quickly connect the NI 783xR
NSC68-262650 Non-shielded cable connects
from 68-pin VHDCI male
connector to two 26-pin
female headers plus one
50-pin female header. The
pinout of these headers
allows for direct connection
to 5B backplanes for analog
signal conditioning and SSR
backplanes for digital signal
conditioning. MIO only 26-pin headers can connect
to the following 5B
backplanes for analog signal
conditioning:
• 5B08 (8-channel)
• 5B01 (16-channel)
50-pin header can connect to
the following SSR
backplanes for digital signal
conditioning:
• 8-channel backplane
• 16-channel backplane
• 32-channel backplane
NSC68-5050 Non-shielded cable connects
from 68-pin VHDCI male
connector to two 50-pin
female headers. The pinout
of these headers allows for
direct connection to SSR
backplanes for digital signal
conditioning. DIO only 50-pin headers can connect
to the following SSR
backplanes for digital signal
conditioning:
• 8-channel backplane
• 16-channel backplane
• 32-channel backplane
Table 1-2. Cables and Accessories (Continued)
Cable Cable Description
NI 783xR
Connector Accessories
