Appendix A Specifications
© National Instruments Corporation A-3 NI 783xR User Manual
Settling Time
Crosstalk................................................. –80 dB, DC to 100 kHz
Analog Output
Output Characteristics
Output type............................................. Single-ended, voltage output
Number of channels
NI 7830R......................................... 4
NI 7831R......................................... 8
NI 7833R......................................... 8
Resolution .............................................. 16 bits, 1 in 65,536
Update time ............................................ 1.0
µs
Max update rate...................................... 1 MS/s
Type of DAC.......................................... Enhanced R-2R
Data transfers ......................................... Interrupts, programmed I/O
Step Size
Accuracy
16 LSB 4 LSB 2 LSB
±20.0 V
7.5 µ s 10.3 µ s 40 µ s
±2.0 V
2.7 µ s 4.1 µ s 5.1 µ s
±0.2 V
1.7 µ s 2.9 µ s 3.6 µ s
