Section 5
Port and Starboard Ballast
Tanks
CORC0230
REAR
BALLAST TANK
PORT
TANK PUMP
STARBOARD
TANK PUMP
STARBOARD
INTAKE/DRAIN
VALVE
PORT
INTAKE/DRAIN
VALVE
REAR
BALLAST TANK
VENT
VENT
