Chapter 2 Installation and Configuration
© National Instruments Corporation 2-11 NI 8171 Series User Manual
Using the Controllers with PXI-1020 and
PXI-1025 Chassis
The NI 8176 and NI 8175 controllers interface directly to the National
Instruments PXI-1020 and PXI-1025 chassis. The interface contains
signals to interface to the chassis LCD display, IDE CDROM drive,
and PS2 mouse and keyboard.
LCD Display
To enable/disable the LCD display for a PXI-1020 or PXI-1025 chassis:
1. Install the controller in a PXI-1020 or PXI-1025 chassis.
2. Connect a CRT monitor to the VGA connector on the NI 8171 series
controller.
3. Power on the chassis and enter the BIOS setup program during the
boot. (When the message Press to enter SETUP appears,
press or on the numeric keypad. The message
Entering Setup… appears, and the setup program is loaded after a
short delay.)
4. In the PXI Setup menu, set the LCD chassis setting to the correct
value:
• PXI-1020—Enables the LCD display and sets the resolution to
640
× 480.
• PXI-1025—Enables the LCD display for the PXI-1025 chassis
and sets the resolution to 800
× 600.
• Disabled—Disables the LCD display even if the controller is
installed in a PXI-1020 or PXI-1025 chassis.
Note If an LCD display does not exist or is malfunctioning, the BIOS Setup option is not
visible.
IDE CD-ROM Drive
The PXI-1020 and PXI-1025 chassis have integrated CD-ROM drives. The
BIOS automatically detects the CD-ROM and enables the IDE interface.
The OS loads drivers to access the CD-ROM. Refer to the
Boot Setup Menu
section for information on booting from the CD-ROM drive.
