HB Series Draper Header Specifications
21HB 25HB 30HB 36HB
Page 4 of 5
MODEL 21HB 25HB 30HB 36HB
VERSIONS AVAILABLE
Single-knife drive, standard deck
x x
Single-knife drive, double swath x x
Double-knife drive, standard deck x x x
Double-knife drive, double swath x x x x
HEADER
Cutting width, ft. (m)
21 (6.4) 25 (7.6) 30 (9.1) 36 (11)
Approximate weight (includes reel), lbs. (kg) 3880 (1760) 4135 (1875) 5021 (2278) 5434 (2465)
Cutting height (minimum), in. (mm) 1.0 (25)* 1.0 (25)* 1.0 (25) 1.0 (25)*
Castering gauge wheels NA Optional Standard Standard
Standard deck center windrow
width opening, in. (m) NA 80 (2.03) 80 (2.03) 80 (2.03)
Double swath center windrow
width opening, in. (m) 50 (1.27) 56 (1.42) 56 (1.42) 56 (1.42)
Slow speed header transport kit ..............................................................................................................Standard .....................................................................................................
Transport height, in. (m) ................................................................................................40 (1.02) from tip of guards to ground)* ...........................................................................
CUTTERBAR
Cutting system ............................................................................Choice of New Holland dual-knife system or Schumacher single-or dual-knife system ........................................
Knife drive...................................................................................................Schumacher hydraulically-driven, planetary-reduction sickle drive........................................................
Sickles
2 1 or 2 1 or 2 2
Sickle speed - strokes per minute...............................................................................................................1400 ........................................................................................................
Sickle stroke, in. (mm) ............................................................................................................................3.31 (84).....................................................................................................
Hay guards...............................................................................................................................................Standard .....................................................................................................
REELS
Type
Steel ..........Pick-up with steel or plastic fingers .......... Plastic fingers
Speed range 20–48 rpm 20–48 rpm 20–48 rpm 20–48 rpm
Drive .........................................................................................................................Direct hydraulic drive w/ 45 cu. in. (.74 L) motor ....................................................................
Hydraulic reel fore / aft adjustment
Standard Optional Optional Standard
DRAPER BELTS
Belt width and construction................................42 in. (1.07 m) rubberized polyester belt with fiberglass reinforcement, tie bar end connection and molded V-Guide................
Speed range, ft. (m) ......................................................................................................................0 - 705 (215) / minute ..........................................................................................
In cab canvas-speed control....................................................................................................................Standard .....................................................................................................
Angle..................................................................................................................................................10 to 20 degrees...............................................................................................
Double swath shift means .......................................................................................................................Hydraulic.....................................................................................................
* with 18.4 x 26 drive tires
OPTIONS (factory-installed)
• Poly cutterbar skid plates
• End-gauge wheels
• Castering gauge wheels for 25HB
• Cross auger kit
