Napoleon Fireplaces EF30G - Manual (Page 8)

W415-0760 / 12.19.08
8
2
35
W
IF YOU PUT IN THE TEMPERATURE
SENSOR ON THE WALL.PLS CHOOSE 2
IF YOU USE THE
TEMPERATURE
SENSOR.PLS CHOOSE 1
2
1
TEMPERATURE
CONTROL SWITCH
t
10
-1
0
5-5
4-4
10 - 10
1-1
9-9
6-6
2-2 3-3
12-12 8-8
PTC
t105!
REMO.
SIP2
RECEIVER
MAIN CONTROL
POWER
2
35
W
N
L
FL
AM
E M
O
TO
R
~M
BL
O
W
ER
M
O
TO
R
H
EA
TE
R
2
~M
H
EA
TE
R
1
TEMPERATURE
SENSOR
t
[
+
k
_
RG
TEM.
P-N0
H2 H1+
FAN
P-L
P-NI
MOTOR
LAMP FIRE
7-7
3.3 hardwire installation
figurE 3.3
ElECTriC diagram
!
WARNING
Ensure all power is turned off before hard wiring this fireplace.
tp - hardWire Warning
If it is necessary to hard wire this appliance, a qualified electrician may remove the cord connection, and wire
the appliance directly to the house hold wiring.
this appliance must be electrically connected and grounded in accordance with local codes, if hard wired. in
the absence of local codes, use the current csa c22.1 canadian electrical code in canada or the
ansi/nfpa 70-1996 national electrical code in the united states.
