Napoleon Fireplaces EF30G - Manual (Page 7)

7
W415-0760 / 12.19.08
3.0 electrical requirements
this appliance is for use on 120 volts. the cord has a plug as
shown in (a) of figure 1 given below. an adapter as shown in
(c) is available for connecting three-blade grounding type plugs
to two-slot receptacles. the green grounding lug extending
from the adapter must be connected to a permanent ground
such as a properly grounded outlet box. the adapter should
not be used if a three-slot grounded receptacle is available.
to disconnect appliance, turn controls to off, then remove plug
from outlet.
figurE 3.1
3.1 grounding appliance
