New Holland T4O3O - Manual (Page 15)

F
G
C B
A
D
E
Operator environment
Rubber isolation blocks ● ● ●
Lateral levers ● ● ●
Suspended platform (with mid mounted foldable ROPS) ● ● ●
Electronic instrumentation ● ● ●
Cab O O O
Air conditioning O O O
Blue Cab ● ● ●
Max. noise level*** (dBA) 79 79 79
Dimensions & Weights****
A Wheelbase 4WD (mm) 2093 – – 2093 – – 2180 – –
A Wheelbase SuperSteer™ 4WD front axle (mm) – 2348 2348 – 2348 2348 – 2435 2435
B Overall length 4WD (mm) 3925 3914 3914 3925 3914 3914 4012 4001 4001
C Minimum overall width (mm) 1061 1229 1398 1061 1229 1398 1061 1229 1398
D Height to top of ROPS (mm) 2249 2274 2274 2249 2274 2274 2335 2360 2274
D Height to top of cab (mm) 2148 2173 2173 2148 2173 2173 2148 2173 2173
E Height at centre rear axle to top of cab (mm) 1648 1648 1648
F Ground clearance min (mm) 270 290 323 270 290 323 270 290 323
G T4000V front wheel track setting 4WD (mm) 879 - 985 879 - 985 879 - 985
G T4000N front wheel track setting 4WD (mm) 1075 - 1251 1075 - 1251 1075 - 1251
G T4000F front wheel track setting 4WD (mm) 1062 - 1492 1062 - 1492 1190 - 1492
G T4000V rear wheel track setting 4WD (mm) 861 - 1261 861 - 1261 861 - 1261
G T4000N rear wheel track setting 4WD (mm) 1003 - 1273 1003 - 1273 1003 - 1273
G T4000F rear wheel track setting 4WD (mm) 1130 - 1530 1130 - 1530 1108 - 1371
T4000V Weights***** 2WD/4WD (kg) 2459 / 2710 2459 / 2710 2531 / 2790
T4000N Weights***** 2WD/4WD (kg) 2546 / 2762 2546 / 2762 2618 / 2852
T4000F Weights***** 2WD/4WD (kg) 2840 / 2910 2840 / 2910 2930 / 3000
Max. permissible weight (kg) 3800 4000 4300 3800 4000 4300 3800 4000 4300
*Developed by Fiat Powertrain Technologies **Conditions apply ***Cab model only ****Rear Tyres T4000 F = 340/85R28, T4000N = 320/85R24, T4000V 280/85R28 *****With driver (85kg) and full fuel tank
● Standard O Optional – Not available
MODELS T4030V I N I F T4040V I N I F T4050V I N I F
