39
W415-0153 / B / 06.10.10
COMMON COMPONENTS
REF NO. PART NO. DESCRIPTION
26* W380-0002 VARIABLE SPEED SWITCH KNOB
27 KB-35 VARIABLE SPEED SWITCH
28 GZ552 REPLACEMENT BLOWER
29 W030-0022 ACCENT BAR
30 W200-0077 BLACK TRIVET
31 W300-0038 FRONT WINDOW GLASS
32 W300-0037 SIDE WINDOW GLASS
33 W562-0022 GLASS GASKET
GS28 COMPONENTS
REF NO. PART NO. DESCRIPTION
34 W010-0459 ADAPTOR C/W SPILL SWITCH
35 W660-0006 SPILL SWITCH
TERMINAL KITS
REF NO. PART NO. DESCRIPTION
GD175 - WALL TERMINAL KIT
36 BM6790 90° ELBOW - 7" DIAMETER
37 GD-222 TERMINAL ASSEMBLY
38 BM67ADJ 30" TO 53" ADJUSTABLE PIPE - 7"DIAMETER
39 W010-1313 FIRESTOP / WALL PLATE
40 W585-0267 TOP VENT SHIELD
41* W020-0032 HARDWARE
42 BM6724 24" STOVE PIPE - 7" DIAMETER
43 BM3730 BLACK TRIM COLLAR
44* W010-0300 10' ALUMINUM FLEX LINER C/W SPACERS - 4" DIAMETER
45 W025-0003 DECORATIVE BLACK BAND
GD180 - PERISCOPE TERMINAL KIT
36 BM6790 90° ELBOW - 7" DIAMETER
46 GD-201 PERISCOPE
38 BM67ADJ 30" TO 53" ADJUSTABLE PIPE - 7"DIAMETER
39 W010-1313 FIRESTOP / WALL PLATE
40 W585-0267 TOP VENT SHIELD
41* W020-0032 HARDWARE
42 BM6724 24" STOVE PIPE - 7" DIAMETER
43 BM3730 BLACK TRIM COLLAR
44* W010-0300 10' ALUMINUM FLEX LINER C/W SPACERS - 4" DIAMETER
45 W025-0003 DECORATIVE BLACK BAND
ROOF TERMINAL KITS
REF NO. PART NO. DESCRIPTION
GD110 - ROOF TERMINAL KIT - 1/12 TO 7/12 PITCH
47 W490-0073 4/7 INNER/OUTER SLEEVE
48 W670-0006 TERMINAL, 4/7
49 W010-0567 ROOF SUPPORT
50 W170-0063 STORM COLLAR
51 W263-0054 FLASHING
GD111 - ROOF TERMINAL KIT - 8/12 TO 12/12 PITCH
47 W490-0073 4/7 INNER/OUTER SLEEVE
48 W670-0006 TERMINAL, 4/7
49 W010-0567 ROOF SUPPORT
50 W170-0063 STORM COLLAR
52 W263-0055 FLASHING
