9.0 REPLACEMENTS
Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally
all parts can be ordered through your Authorized dealer / distributor.
FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE
REQUIRED TO HONOUR THE CLAIM.
When ordering replacement parts always give the following information:
•
Model & Serial Number of appliance
• Installation date of appliance
• Part number
• Description of part
• Finish
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR FURTHER INFORMATION, CONTACT YOUR
AUTHORIZED DEALER.
41.2
FAILURE TO POSITION THE PARTS IN ACCORDANCE WITH THIS MANUAL OR FAILURE TO USE
ONLY PARTS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY
DAMAGE OR PERSONAL INJURY.
** THIS IS A FAST ACTING THERMOCOUPLE. IT IS AN INTEGRAL SAFETY COMPONENT. REPLACE ONLY WITH
A FAST ACTING THERMOCOUPLE SUPPLIED BY WOLF STEEL LTD.
!
WARNING
COMMON COMPONENTS
REF NO. PART NO. DESCRIPTION
1 W725-0042 SIT VALVE - NG
1 W725-0048 SIT VALVE - LP
2* W100-0056 BURNER
3 W455-0026 #38 BURNER ORIFICE - NG
3 W455-0003 #54 BURNER ORIFICE - LP
4 W010-0550 PILOT ASSEMBLY - LP
4 W010-0633 PILOT ASSEMBLY - NG
5 W455-0052 PILOT ORIFICE - LP
5 W455-0062 PILOT ORIFICE - NG
6 W680-0008 THERMOCOUPLE **
7 W680-0004 THERMOPILE
8 W290-0029 PILOT GASKET
9* W010-0865 EMBER SCREEN ASSEMBLY
10 W357-0001 PIEZO IGNITOR
11* W475-0235 CONTROL PANEL
12 GL-620 4PC LOG ASSEMBLY C/W EMBERS
13 W135-0058 FRONT LOG
14 W135-0059 BACK LOG
15 W135-0060 RIGHT LOG
16 W135-0061 LEFT LOG
17* W361-0016 GLOWING EMBERS
18* W550-0001 CHARCOAL EMBERS
19* W290-0043 BURNER GASKET
20* W385-0351 NAPOLEON LOGO
21* W290-0045 BLOWER ACCESS GASKET
22 W430-0002 MAGNETIC CLOSURE
23 W390-0002 LATCH
24* W660-0009 ON/OFF SWITCH
25 W690-0002 THERMAL SWITCH
