25
Essentia Specifications
Warranty
NUVO Technologies warrants this product to be free of
defects in workmanship or material for a period of
three (3) years from the original date of purchase. This
warranty applies to the original purchaser only and is
not transferable. This warranty is subject to the follow-
ing conditions and exclusions:
• Defects caused by wear and tear, misuse, or
neglect are not covered by this warranty.
• This warranty will be void if:
a. The unit has been altered or modified.
b. The serial number has been removed
or defaced.
c. Original purchase is not from an
Authorized NUVO Dealer.
d. The warranty card is not completely
filled out and mailed within 10 days of
the original purchase.
Neither NUVO Technologies, nor NUVO dealers are
liable for any incidental or consequential damages
resulting from any defect in or failure of NUVO
Technologies products. This warranty gives the origi-
nal owner of NUVO Technologies products specific
legal rights, and he or she may also have other rights
which vary from state to state. This warranty is
expressly in lieu of all other agreements and war-
ranties, expressed or implied, except as may be other-
wise required by law.
Essentia D Specifications
Zones 1-6 Power Amplifier Outputs
Continuous Average Output Power (per zone)
40W (20W x 2)
Two channels driven 30-20kHz @1% THD
Rated Distortion (THD 1/2 power)
0.40%
Rated Impedance 6 Ohms
Damping Factor 50+
Frequency Response (20-20kHz) ±2dB
Zones 1-6 Preamplifier Outputs
Variable output
0-600mV
Fixed output 600mV
Output Impedance 600 Ohms
Source Inputs 1-6
Input Impedance
10K
Input Sensitivity for rated power 300mV RMS
Input Overload 3V RMS
Emitter Outputs
Source Outputs
6
Sum Outputs 2
Output Drive Current 100mA
Output Drive Voltage 12V
Compatible with single and dual emitters
System
System On
12V @ 50mA
External Mute 3-12V DC
Zone Trigger Outputs
Output Power
12V @ 50mA
Outputs 6 (zones 1-6)
Power Requirements
Power Supply
120VAC/240VAC 50/60Hz
Power Consumption all channels 340VA (290W)
driven to full-rated power
Power Consumption average
50VA (40W)
operating conditions
Power Consumption no signal
18VA (12.5W)
USA Safety Listing (UL 6500) Pending
Canada Safety Listing (CAN/CSA E60065.00) Pending
CE Listing/SEMKO (EN60065, EN55013, Pending
EN55020, EN6100-3-2, EN6100-3-3/A1)
Physical Specifications
Unit Size Millimeters
88 x 430 x 325
Unit Size Inches 3 1/2 x 17 x 12 3/4
Shipping Size Millimeters 290 x 540 x 440
Shipping Size Inches 11 3/8 x 21 1/4 x 17 3/8
Unit Weight Kilograms 7.8
Unit Weight Pounds 17.0
Shipping Weight Kilograms 12.7
Shipping Weight Pounds 28.0
NuVo reserves the right to change specifications without notice.
Essentia package comes complete with the following:
•
Essentia six-source, six-zone amplifier
• Six keypads with white, ivory, and almond cover plates for
each, and 36 replacement buttons
• RC2 remote control with batteries
• EZ-Port Cat-5 connection hub
• Network cable
• Six infra red emitters
Essentia Expander package (for an additional six zones of sound)
comes complete with the following:
•
Essentia six-source, six-zone amplifier
• Six keypads with white, ivory, and almond cover plates for
each, and 36 replacement buttons
• RC2 remote control with batteries
• Audiolink and Datalink connecting cables
